8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Manage Device Security User Manual359
For information about the credentials, see Credentials for the local browser interface on
page 32.
5. Click the Login button.
The System Information page displays.
6. Select Security >
ACL > ACL Wizard.
The previous figure shows the ACL Wizard for model GS110TPv3.
7. From the ACL T
ype menu, select the type of ACL.
You can select from the following ACL types:
• ACL Based on Destination MAC. Creates an
ACL based on the destination MAC
address, destination MAC mask, and VLAN.
• ACL Based on Source MAC. Creates an
ACL based on the source MAC address,
source MAC mask, and VLAN.
• ACL Based on Destination IPv4. Creates an
ACL based on the destination IPv4
address and IPv4 address mask.
• ACL Based on Source IPv4. Creates an
ACL based on the source IPv4 address and
IPv4 address mask.
• ACL Based on Destination IPv6. Creates an
ACL based on the destination IPv6
prefix and IPv6 prefix length.
• ACL Based on Source IPv6. Creates an
ACL based on the source IPv6 prefix and
IPv6 prefix length.
• ACL Based on Destination IPv4 L4 Port. Creates an
ACL based on the destination
IPv4 Layer 4 port number.
