8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure System Information User Manual99
detects that the attached PD requests more power than IEEE 802.3af but is not an
IEEE 802.3at Class 4 device, the PD does not receive power from the switch.
11. From the Power Limit Type menu, select how the port controls the maximum power that it
can deliver:
• None. The port draws up to Class 0 maximum power in low power mode and up to
Class 4 maximum power in high power mode.
• Class. The port power limit is equal to the class of the attached PD.
• User. The port power limit is equal to the value that is specified in the Power Limit
(mW) field. This is the default setting.
Note: If a PD does not report its class correctly, use of these options can
preserve additional PoE power by preventing the switch from
delivering more power than the PD requires. However, depending on
which option you select, a PD that does not report its class correctly
might not power up at all.
12. In the Power Limit (mW) field, enter the maximum power (in mW) that the port can deliver.
The range is 3,000–30,000 mW. The default is 30,000 mW.
13. From the Detection Type menu, select how the port detects the attached PD:
• IEEE 802. The port performs a 4-point resistive detection. This is the default setting.
• 4pt802.3af+legacy. The port performs a 4-point resistive detection, and if required,
continues with legacy detection.
• Legacy. The port performs legacy detection.
14. From the Timer Schedule menu, select a timer schedule or select None, which is the
default selection.
For information about setting up and configuring PoE timer schedules, see Set up PoE
timer schedules on page 131.
15. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable fields on the page.
Table 22. PoE Port Configuration
Field Description
High Power All ports supports high power mode.
Power Limit (mW) The maximum power in milliwatts that can be provided by the port.
