18 Océ 9300 User Manual
Bits combination
When transmitting data via the serial interface, 8 or 7 bits per byte are used.
The default is 8.
▼
Defining the bits combination
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
CONNECTIONS
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
CONNECTIONS
’ menu.
6
Select the ‘
SERIAL
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
SERIAL
’ menu.
8
Select the ‘
TRANSMISSION
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
TRANSMISSION
’ menu.
10
Select the ‘
BAUD RATE
’ item using the or button.
11
Press ‘next/select’ to enter the ‘
BAUD RATE
’ menu.
12
Select the number of bits per byte using the or button.
13
Press ‘next/select’ to confirm the selected number of bits.
14
Press ‘Program’ to leave the main menu.
Serial parity and stop bits
For correct data transfer, the parity and stop bits (framing) are required. You
can select the following combinations:
■
None, 1 stop No parity, 1 stop bit
■
None, 2 stopNo parity, 2 stop bits
■
Even, 1 stopEven parity, 1 stop bit
■
Even, 2 stopEven parity, 2 stop bits
■
Odd, 1 stopOdd parity, 1 stop bit
■
Odd, 2 stopOdd parity, 2 stop bits
Default is NONE, 1 STOP
▼
Setting the parity and stop bits
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
CONNECTIONS
’ item using the or button.
