42 Océ 9300 User Manual
Cut method
This setting can be used to select standard cut or synchro cut.
Note:
Use Synchro Cut when you have to define a non-standard paper size in
your application.
The values selected for leading or trailing edge are taken into account when
using Synchro Cut.
▼
Programming cut method
1
Press ‘Program’ to enter the main menu.
2
Select ‘
MEDIA
SETTING
’
item using the or button.
3
Press ‘next/select’ to enter the ‘
MEDIA
SETTING
’
menu.
4
Select the ‘
PLOT
POSITION
’
item using the or button.
5
Press ‘next/select’ to enter the ‘
PLOT
POSITION
’
menu.
6
Select the ‘
CUT
METHOD
’
item using the or button.
7
Press ‘next/select’ to enter the ‘
CUT
METHOD
’
menu.
8
Select the desired cut method using the or button.
9
Press ‘next/select’ to confirm the selected cut method.
10
Press ‘Program’ to exit the main menu.
Plot Center
This setting can be used to enable or disable centering of the plot on the paper.
If the center setting is disabled, the plot will be positioned in the upper
left-hand corner of the page.
If Standard Cut is selected, the plot is printed and the media is cut according to
the standard cut functionality. If Plot Center in ON, the plot is shifted up/down
and left/right to be centered on the selected bounding box.
Note:
If you print a plot that exceeds standard length, the machine
automatically switches to synchro cut to prevent you from losing information.
If Synchro Cut is selected, the bounding box of the plot sets hard clip limits. If
Plot Center is ON, the plot is shifted left/right to be centered on the page.
