64 Océ 9300 User Manual
▼
▼▼
▼
Setting the End of Message parameter
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
DATA FORMAT
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
DATA FORMAT
’ menu.
6
Select the ‘
CALCOMP SETUP
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
CALCOMP SETUP
’menu.
8
Select the ‘
END OF MESSAGE
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
END OF MESSAGE
’menu.
10
Select the required value using the or button.
11
Press ‘next/select’ to confirm the selected value.
12
Press ‘Program’ to exit the main menu.
Synchronization code parameter
The synchronization code parameter is significant in all cases in which
CalComp format is selected or auto-recognized, when select format is set to
Auto or a remote control command for CalComp has been sent.
The range of permitted values is 0 to 63
DEC
inclusive. The selected value is
the decimal equivalent of the byte interpreted as the beginning of a print data
block. The default synchronization code is 2.
▼
▼▼
▼
Setting the synchronization code parameter
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
DATA FORMAT
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
DATA FORMAT
’ menu.
6
Select the ‘
CALCOMP SETUP
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
CALCOMP SETUP
’menu.
8
Select the ‘
SYNC CODE
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
SYNC CODE
’. menu.
10
Select the required sync code using the or button.
11
Press ‘next/select’ to confirm the selected sync code.
12
Press ‘Program’ to exit the main menu.
