Oce 9300 - Transformation Functions; Print Rotation; Print Scaling

Advanced menu functions 83
Transformation
The Océ 9300 allows the user to change the position of the image on the print
in the following ways: Image rotation and scaling functions. This applies only
to
vector
languages and is possible only when the media saver is switched off.
Print rotation
This function allows you to set the degree of rotation applied to a print. Four
rotation values are possible: 0°, 90°, 180°, and 270°. The default is 0°. This
function applies only to vector languages.
▼
Defining the print rotation
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
PLOT MANAGER
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
PLOT MANAGER
’ menu.
6
Select the ‘
TRANSFORM
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
TRANSFORM
’ menu.
8
Select the ‘
ROTATION
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
ROTATION
’menu.
10
Select the required value using the or button.
11
Press ‘next/select’ to confirm the setting.
12
Press ‘Program’ to exit the main menu.
Print scaling
The X-scale and Y-scale can be individually set to values ranging from 0.05 to
20.0. The default is 1.0. This function applies only to vector languages.
▼
Defining print scaling
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
PLOT MANAGER
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
PLOT MANAGER
’ menu.
