84 Océ 9300 User Manual
6
Select the ‘
TRANSFORM
’
item using the or button.
7
Press ‘next/select’ to enter the ‘
TRANSFORM
’
menu.
8
Select the ‘
SCALING
’
item using the or button.
9
Press ‘next/select’ to enter the ‘
SCALING
’ menu.
10
Select the required scaling method using the or button.
11
Press ‘next/select’ to enter the appropriate menu.
Follow the procedure below to define scaling for the X and Y axis individually:
12
Select the required setting using the or button.
13
Press ‘next/select’ to confirm the setting.
14
Press ‘Program’ to exit the main menu.
Note:
When autoscale is selected, x-scaling and y-scaling are not applicable.
Autoscaling
The purpose of Autoscale is to apply exact ISO/ANSI/Architect formats to
documents. The same scaling factor is applied to the X and Y axis. An auto
rotation can be performed to attain the best auto scale factor.
Although the Media Saver and the Autoscaling Mode are controlled separately,
they do interact.
Autoscale mode can be activated in two ways:
■
Autoscale to a predefined format (ISO/ANSI/Architect)
■
best fit
The user can combine Autoscale and Autoposition: plots are first autoscaled
(best fit or scale to format, if required), and then autopositioned (if required).
Fit-to-Format Mode:
All the drawings regardless their sizes, are reduced/enlarged to one specific
standard size. This option can be combined with the Media Saver option.
The list of predefined formats depends on the media format selected via the
printer operating panel.
Users can enlarge drawings to poster size in order to make presentations to
large audience. They can also reduce documents to easily mail them or archive
them in standard A3 (11x17") or A4 (8.25x11") books.
