Oce 9300 - Serial Port Type Selection

Installing the printer 19
5
Press ‘next/select’ to enter the ‘
CONNECTIONS
’ menu.
6
Select the ‘
SERIAL
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
SERIAL
’ menu.
8
Select the ‘
TRANSMISSION
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
TRANSMISSION
’ menu.
10
Select the ‘
FRAMING
’ item using the or button.
11
Press ‘next/select’ to enter the ‘
FRAMING
’ menu.
12
Select the appropriate parity and number of stop bits using the or button.
13
Press ‘next/select’ to confirm the selected parity and number of stop bits.
14
Press ‘Program’ to leave the main menu.
Port type
In order to give the maximum connection flexibility, the printer’s serial port
can be set to either DTE (data terminal equipment) or DCE (data
communications equipment). The default is DTE.
▼
Selecting the port type
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
CONNECTIONS
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
CONNECTIONS
’ menu.
6
Select the ‘
SERIAL
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
SERIAL
’ menu.
8
Select the ‘
PROTOCOL
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
PROTOCOL
’ menu.
10
Select the ‘
PORT
’ item using the or button.
11
Press ‘next/select’ to enter the ‘
PORT
’ menu.
12
Select the appropriate port using the or button.
13
Press ‘next/select’ to confirm the selected port.
14
Press ‘Program’ to leave the main menu.
Note:
The printer's serial interface conforms to the RS-232-C and
RS-423-C standards. If your computer uses the RS-423-C serial interface,
the port type must be set to DTE.
