Oce 9300 - CalComp Merge Mode; CalComp End of Message Parameter

Customizing defaults 63
10
Select the required pen priority using the or button.
11
Press ‘next/select’ to confirm the selected pen priority.
12
Press ‘Program’ to exit the main menu
Merge mode
This option determines what happens when two or more colors intersect at the
same point of a plot, especially in area fills. The default setting is ‘On’.
Merge Off
Only the last color specified is printed for a given line or area. The
other colors specified for the same line or area are transparent.
Merge On
All the specified colors are blended together.
▼
▼▼
▼
Setting the merge mode
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
DATA FORMAT
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
DATA FORMAT
’ menu.
6
Select the ‘
CALCOMP SETUP
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
CALCOMP SETUP
’ menu.
8
Select the ‘
MERGE
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
MERGE
’ menu.
10
Select ‘
YES
’ or ‘
NO
’ using the or button.
11
Press ‘next/select’ to confirm the selected setting.
12
Press ‘Program’ to exit the main menu.
End of Message parameter
The End of Message (EOM) parameter is significant in all cases in which the
CalComp format is selected or auto-recognized, and select format is set to
Auto or a remote control command for CalComp has been sent.
The range of permitted values is 0 to 31
DEC
inclusive. The selected value is
the decimal equivalent of the byte indicating the end of the data sequence. It
should be a unique character from the character set used to encode the data.
The default EOM is 3.
