46 Océ 9300 User Manual
Defining pen settings
You can change the pen settings for the files you want to print in the pen menu.
The default width and pattern for each pen number can be changed in this
menu. These settings apply to all vector languages: HP-GL, HP-GL/2
CalComp.
Pen width can be defined from 0.08 up to 10.75 mm (0.0031" to 0.423"). All
pen widths are set to 0.25 mm (0.009") by default. Adjustments can be made
in increments of 0.01 mm.
A pen can be selected by the plot file to draw a line or to fill a polygon. All
lines or polygons on the plot can be drawn with a predefined pattern or shade
of gray. Pen pattern 16 is the default. The following pen patterns are available:
[20] Available pen patterns
white
black
