62 Océ 9300 User Manual
Checksum parameter
The checksum parameter is significant in all cases in which the CalComp
format is selected or auto-recognized, and select format is set to Auto or a
remote control command for CalComp has been sent. The default is Yes.
▼
▼▼
▼
Defining the checksum parameter
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘
CONFIGURATION
’ menu.
4
Select the ‘
DATA FORMAT
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
DATA FORMAT
’ menu.
6
Select the ‘
CALCOMP SETUP
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
CALCOMP SETUP
’menu.
8
Select the ‘
CHECKSUM
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
CHECKSUM
’ menu.
10
Select ‘
YES
’ or ‘
NO
’ using the or button.
11
Press ‘next/select’ to confirm the selected setting.
12
Press ‘Program’ to exit the main menu.
CalComp pen priority
You can define pen parameters in the print file, either in a remote configuration
file or from the printer control panel. The pen priority option allows you to
define which set of pen parameters you want to use.
If ‘
Language’
is selected, the pen parameters defined in the data file will be
used. If ‘
Setup’
is selected, the pen parameter defined on the printer operating
panel, or in the optional remote configuration file, will be used. The default is
Language.
1
Press ‘Program’ to enter the main menu.
2
Select the ‘C
ONFIGURATION
’ item using the or button.
3
Press ‘next/select’ to enter the ‘C
ONFIGURATION
’ menu.
4
Select the ‘
DATA FORMAT
’ item using the or button.
5
Press ‘next/select’ to enter the ‘
DATA FORMAT
’ menu.
6
Select the ‘
CALCOMP SETUP
’ item using the or button.
7
Press ‘next/select’ to enter the ‘
CALCOMP SETUP
’ menu.
8
Select the ‘
PEN PRIORITY
’ item using the or button.
9
Press ‘next/select’ to enter the ‘
PEN PRIORITY
’ menu.
