Olivetti PR2 - Page 47

Service Manual
683311W
3-13
- Push the ribbon guide downwards until it releases from the print carriage.
- Remove the old cartridge by pulling it outwards.
Fig 3-12 Removing the Ribbon Cartridge
- Insert the cartridge into the feed gear by hooking it on the two sides.
Fig. 3-13 Hooking the Cartridge to the Structure
3
