Omron CQM1H - 08-2005 User Manual

147
Connecting the Programming Console Section 7-2
C200H-PRO27-E
The following table shows the connecting cables that can be used to connect
the C200H-PRO27-E to the CQM1H.
CQM1H-PRO01-E/CQM1-PRO01-E Key Sheet
Model number Connection Length
C200H-CN222 Connect to the Peripheral port of a CS1W-CN114
Connecting Cable.
2 m
C200H-CN422 4 m
CS1W-CN224 Connect directly to the CQM1H’s peripheral port. 2 m
CS1W-CN624 6 m
Mode switch
LCD area
Operation keys
Casette jacks
Not used with the CQM1H.
SHIFT
FUN
AND
LD
SFT
NOT
OR
OUT
CNT
TIM
TR
*EM
LR
CH
*DM
HR
CONT
*
CLR
EM
DM
PLAY
EXT
SET
REC
RESET
VER
CHG SRCH
DEL
INS
WRITE
MONTR
SHIFT
SHIFTFUN
AND
LD
SFT NOT
OR
OUT
CNT
TIM
TR
*EM
LR
CH
*DM
CONT
*
CLR
EM
DM
EXT
SET
RESET
VER
CHG SRCH
DEL
INS
WRITE
MONTR
AR
HR

Omron CQM1H - 08-2005 Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Omron
Program Capacity	3.2K steps
Model	CQM1H
I/O Points	512 points max
