Connecting the Programming Console Section 7-2
Key Functions The following table lists the basic uses of the Programming Console keys.
Mode Switch The mode switch controls the CQM1H’s operating mode. The key can be
removed when the switch is set to RUN or MONITOR but it cannot be
removed when the switch is set to PROGRAM.
Key Normal input SHIFT Key input Key Normal input SHIFT Key input
Function code --- Expansion function ---
SFT(10) instruction --- Data change ---
NC condition or
differentiated instruction
--- Search operation ---
Shift mode --- Force-setting a bit ---
AND instruction --- Deletion ---
OR instruction --- Monitoring ---
COUNTER instruction
(CNT) or counter
address
--- Force-resetting a bit ---
TR bits --- Insertion ---
LR address Indirect EM address Clearing the display or
canceling an operation
---
HR address AR address Verifications ---
LD instruction --- Writing ---
OUT instruction --- Moving to previous
memory, bit, or word
address
Upward differentiation
TIMER instruction (TIM)
or timer address
--- Moving to next memory,
bit, or word address
Downward differentia-
tion
DM address EM address Inputting digits 0 to 9. Inputting hexadecimal
digits A to F.
Indirect DM address IR/SR address
Constant Bit address
FUN
EXT
SFT
CHG
NOT
SRCH
SHIFT
SET
AND
DEL
OR
MONTR
CNT
RESET
TR INS
*
EM
LR
CLR
AR
HR
VER
LD
WRITE
OUT
↑
TIM
↓
EM
DM
A
0
F
5
9
CH
*
DM
CONT
#
