Setting 2D Code Inspection Conditions
FQ-CR2 User’s Manual
4
Setting Up Inspections
51
Detailed Parameters
Each parameter is automatically set by default.
If scanning cannot be performed because the code is different or otherwise, set the detailed parameters
manually and execute teaching.
[Inspect] - [Modify] - [Add item] - [2D-code] - [Details] tab
Detailed Parameter Settings
Parameter Setting Description
Code type DataMatrix
QR Code
Auto (default)
Sets the type of code to be scanned.
Auto length OFF
ON (default)
Sets whether the code length is automatically acquired.
Reverse Normal
Reverse
Auto (default)
Sets normal image or reverse (mirror) image.
Code color Black
White
Auto (default)
Sets the color of the code.
Fast mode ON, OFF (default) Sets fast mode.
When ON, the scanning time is shorter.
For certain work, the scanning time may be longer when Fast mode is ON.
Please use after performing test measurements and verifying the scanning
speed.
Shape
(DataMatrix only)
Square
Rectangle
Auto (default)
Sets the code shape.
QR Code Model
(QR Code only)
Model 1
Model 2
Auto (default)
Sets the QR Code model.
Error Correction Level
(QR Code only)
L (7%)
M (15%)
Q (25%)
H (30%)
Auto (default)
Sets the error correction level (ECC level).
(The ECC level of DataMatrix is fixed at 200.)
Cell
(QR Code only)
21 × 21, 25 × 25, 29 × 29,
33 × 33, 37 × 37, 41 × 41,
45 × 45, 49 × 49, 53 × 53,
57 × 57, Auto (default)
Sets the number of code cells.
Cell
(DataMatrix only)
Shape: Square
10 × 10, 12 × 12, 14 × 14,
16 × 16, 18 × 18, 20 × 20,
22
× 22
, 24 × 24, 26 × 26,
32 × 32, 36 × 36, 40 × 40,
44 × 44, 48 × 48, 52 × 52,
64 × 64, Auto (default)
Shape: Rectangle
8 × 18, 8 × 32, 12 × 26,
12 × 36, 16 × 36, 16 × 48,
Auto (default)
Sets the number of code cells.
FQ Sensor User Manual.book 51 ページ ２０１１年７月８日 金曜日 午後２時３０分
