Setting 2D Code Inspection Conditions
52
FQ-CR2 User’s Manual
• With the exception of "Fast mode", the detailed parameters are set when [Teach] is pressed.
• When the "Code type" setting is changed, some settings are initialized as shown below.
Inspection Data that Can be Logged
The following values can be logged as inspection data.
If an Error Occurs
If a teaching error occurs
If scanning of the 2D code fails, a teaching error message appears. It is likely that low contrast caused unstable
scanning. Adjust the brightness to increase the contrast of the 2D code.
Increasing the Brightness of the Image: p. 36
Parameter Initialized due to "Code type" change
Code type Initialized
Auto length
Reverse
Code color
Fast mode
Shape Initialized
QR Code Model Initialized
Error Correction Level Initialized
Cell Initialized
Inspection item Value range Description
Cell recognition rate 0 to 100 Outputs the cell recognition rate.
FQ Sensor User Manual.book 52 ページ ２０１１年７月８日 金曜日 午後２時３０分
