Omron JX User Manual

15
Contents
Introduction..............................................................................................1
Read and Understand This Manual.........................................................2
Safety Precautions ..................................................................................5
Precautions for Safe Use.........................................................................8
Precautions for Correct Use ....................................................................9
Checking Before Unpacking ....................................................................11
Revision History.......................................................................................12
About This Manual...................................................................................13
Chapter 1 Overview
1-1 Functions .................................................................................................1-2
1-2 Appearance and Names of Parts.............................................................1-4
Chapter 2 Design
2-1 Installation................................................................................................2-2
2-2 Wiring.......................................................................................................2-7
Chapter 3 Operation
3-1 Test Run Procedure.................................................................................3-3
3-2 Test Run Operation .................................................................................3-4
3-3 Part Names and Descriptions of the Digital Operator..............................3-8
3-4 Operation Procedure
(Example: Factory Default)3-10
3-5 Parameter Transition ...............................................................................3-16
3-6 Parameter List .........................................................................................3-17
Chapter 4 Functions
4-1 Monitor Mode...........................................................................................4-2
4-2 Function Mode .........................................................................................4-6
Chapter 5 Maintenance Operations
5-1 Special Display List (Error Codes)...........................................................5-2
5-2 Troubleshooting .......................................................................................5-6
Chapter 6 Inspection and Maintenance
6-1 Inspection and Maintenance....................................................................6-2
6-2 Storage ....................................................................................................6-8

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
