Omron JX User Manual

4-41
4-2 Function Mode
4
Functions
Parameter Initialization
You can initialize the rewritten set values and reset to the factory default, or clear trip records.
Note that this is not available for RUN and power ON times.
The multi-function input/output terminals are also initialized with this function. To avoid unexpected
operation, be sure to re-examine the wiring.
Refer to page 3-5 for more details about the initialization process.
Frequency Conversion Coefficient
This function displays a conversion value obtained by multiplying the Inverter output frequency by
the coefficient set in [b086]. This helps display the actual physical value on the monitor.
Displayed value [d007] = "Output frequency [d001]" x "Frequency conversion coefficient [b086]"
Refer to page
4-3 for more details
STOP Key Selection
You can select whether to enable the STOP key on the Digital Operator, even if the RUN command
is set to the control terminal block (terminal).
•The trip reset function via the STOP/RESET key works according to this setting.
Free-run Stop
This function sets the motor to free running status by shutting off the Inverter output. Also You can
select the operation to be performed when the free-run stop input is reset, and select the stop meth-
od, deceleration stop or free-run stop.
Parameter No. Function name Data Default setting Unit
b084 Initialization selection
00: Clears the trip monitor
01: Initializes data
02: Clears the trip monitor and initializes
data
00 ⎯
b085
Initialization parameter
selection
00: Do not change. 00 ⎯
Parameter No. Function name Data Default setting Unit
b086
Frequency conversion
coefficient
0.1 to 99.9 1.0 ⎯
Related parameters d007
Parameter No. Function name Data Default setting Unit
b087 STOP key selection
00: Enabled
01: Disabled
00 ⎯
Parameter No. Function name Data Default setting Unit
b088 Free-run stop selection
00: 0 Hz start
01: Active Frequency Matching
restart
00 ⎯
b091 Stop selection
00: Deceleration → Stop
01: Free-run stop
00 ⎯
b003 Retry wait time 0.3 to 100. 1.0 s
Related parameters C001 to C005, b003

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
