Omron JX User Manual

4-8
4-2 Function Mode
4
Functions
<Group A: Standard Function Parameter>
Frequency Reference Selection
Select the method of the frequency reference.
* To switch to the 2nd frequency reference, allocate 08 (SET) to the multi-function input terminal and then turn it
on.
RUN Command Selection
Select the method of the RUN/STOP command.
* To switch to the 2nd RUN command, allocate 08 (SET) to the multi-function input terminal and then turn it on.
Parameter No. Function name Data Default setting Unit
A001
Frequency reference
selection
00: Digital Operator (FREQ adjuster)
01: Terminal
02: Digital Operator (F001)
03: ModBus communication
10: Frequency operation result
00 ⎯
*
A201
2nd frequency
reference selection
Related parameters A005, A141 to A143, A145, A146
Data Frequency reference source
00 FREQ adjuster
01 Voltage or current setpoint reference from the terminal.
02 F001 value set via the Digital Operator.
03 ModBus communication
10 Result of the frequency operation function
Parameter No. Function name Data Default setting Unit
A002
RUN command
selection
01: Terminal
02: Digital Operator
03: ModBus communication
02 ⎯
*
A202
2nd RUN command
selection
Related parameters F004, A005, C001 to C005
Data RUN command source
01
Turn ON/OFF by FW and RV allocated to the terminal.
The STOP command is activated if both Forward/Reverse commands are input
simultaneously.
02 Use the RUN and STOP/RESET keys on the Digital Operator.
03 Use the ModBus communication.

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
