Omron JX

7-16
7-4 Options
7
Specifications
Output choke (AX-FEM-RE)
Dimensional Drawing
Specifications
Digital Operator (3G3AX-OP01)
Reference D
diameter
Motor
KW
Dimensions Weight
Kg
LWHXYm
AX-FEM2102-RE 21 < 2.2 85 22 46 70 - 5 0.1
AX-FEM2515-RE 25 < 15 105 25 62 90 - 5 0.2
External dimensions Height (55 mm) × Width (70 mm) × Depth (10 mm)
X
H
YW
Ø m
L
Ø d
Data display
Operation keys
Panel cutout dimension
RUN command
LED indicator
FREQ adjuster
2-M3 Depth 5
8.8
18
16.5 15.3
2-φ4
20.5
18
(7)
10 2.7
