This function draws a rectangle. You can change the size of the rectangle by dragging the four cor-
ners.
The rectangle can be moved by clicking and then dragging the inside of the rectangle.
Wide line
1)
1)
1)
1)
2)
2)
2)
2)
This function draws a wide line.
Y
ou can change the size or direction by dragging the following vertices.
• Vertex (1)
You can change the length or direction of the line by changing the start point or end point.
• Vertex (2)
These allow you to change the width of the line.
The line can be moved by clicking and then dragging the inside of the area.
Ellipse
2)
2)
2)
2)
3)
3)
1)
1)
3)
3)
This function draws a circle or ellipse.
Y
ou can change the size by dragging the following vertices.
• Vertex (1)
These allow you to change the overall size while maintaining the XY ratio.
• Vertex (2)
These allow you change the size in the X direction.
• Vertex (3)
These allow you change the size in the Y direction.
The line can be moved by clicking and then dragging the inside of the area.
4 Configuring Measurement Settings
4 - 8
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
