Processing Unit Registration Editing
Parallel Judgment Output Yes Yes
Data Output Yes Yes
Parallel Data Output Yes Yes
Fieldbus Data Out Yes Yes
Result Display Yes Yes
Display Image File Yes Yes
Display Last NG Image Yes Yes
Conveyor Panorama Display
Yes
*3
Yes
*3
Display Image Hold
Yes
*5
Yes
*5
*1. Sysmac Studio ver.1.09 or later is required to register and edit the processing item(s).
*2. FH Sensor Controller ver.5.20 or later is required to register and edit the processing item(s).
*3. FH Sensor Controller ver.5.50 or later is required to register and edit the processing item(s).
*4. FH Sensor Controller ver.5.70 or later is required to register and edit the processing item(s).
*5. FH Sensor Controller ver.6.10 or later is required to register and edit the processing item(s).
*6. FH Sensor Controller ver.6.20 or later is required to register the processing item(s).
*7. FH Sensor Controller ver.6.30 or later is required to register and edit the processing item(s).
l
List of the processing units supported in Sysmac Studio (FHV tools)
Yes: Supported, No: Not supported
Processing Unit Registration Editing
Camera Image Input Yes No
Camera Image Input FH Yes No
Camera Image Input FHV Yes Yes
Camera Image Input HDR Yes Yes
Measurement Image Switching Yes Yes
Multi-Trigger Imaging Yes Yes
Multi-Trigger Imaging Task Yes Yes
Position Compensation Yes Yes
Filtering Yes Yes
Background Suppression Yes Yes
Brightness Correct Filter Yes Yes
Advanced Filter Yes Yes
Image Subtraction Yes Yes
Color Gray Filter Yes Yes
Extract Color Filter Yes Yes
Anti Color Shading Yes Yes
Stripes Removal Filter II Yes Yes
Polar Transformation Yes Yes
Trapezoidal Correction Yes Yes
Search Yes Yes
Search II Yes Yes
Flexible Search Yes Yes
Sensitive Search Yes Yes
Shape Search III Yes Yes
Classification Yes Yes
Edge Position Yes Yes
Edge Pitch Yes Yes
9 Limitations
9 - 5
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
9-1 Limitations
9
To Next Page
