Omron SYSMAC FH Series Operation Manual

Precautions for Correct Use
The data that the NJ/NX/NY-series Controller manages and the data that the FH/FHV sensor
manages are handled separately on Sysmac Studio except for the I/O Map data that the
NJ/NX/NY
-series Controller manages. The I/O Map is associated to the system data that the
FH/FHV sensor manages. Because of this, the information in the I/O Map will be updated and
changed after editing the data that the FH/FHV sensor controller manages (i.e., the settings da-
ta for the FH/FHV sensor).
Configurations and Setup
Configurations and
Setup
EtherCAT
CPU/Expansion Racks
Data
System data
Tool data
Tasks
I/O Map
Controller Setup
Task Setup
Event Setup
Motion Control Setup
Cam Data Settings
Scene group data
Data that the NJ/NX/NY-series Controller manages
Data that the FH/FHV sensor manages
Project data
1 Overview
1 - 7
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
1-2 Project Management
1
1-2-2 Project Data Handling in Different System Configurations
