Connection through an NJ/NX/NY-series
Controller (when executing an
NJ/NX/NY project)
Ethernet direct connection
(when executing an FH/FHV project)
Downloading the
settings data for the
FH/FHV sensor
The settings data for the FH/FHV sensor is
not downloaded.
Performing the data downloading from
Sysmac Studio will not download the data
that the FH/FHV sensor manages within
the project data that Sysmac Studio man-
ages. Therefore, the settings for the
FH/FHV sensor will not be overwritten.
There are following two methods to down-
load the FH/FHV settings data to the
FH/FHV sensor
.
• Directly connecting to the FH/FHV sen-
sor and downloading the data.
• Extracting the data from Sysmac Studio
and loading it to the FH/FHV sensor via
the external memory.
Downloading the FH/FHV settings data
from Sysmac Studio is possible.
If the FH/FHV sensor is connected to the
computer that runs Sysmac Studio via
Ethernet, downloading the FH/FHV settings
data from Sysmac Studio to the FH/FHV
sensor is possible by transferring the
project data that the Sysmac Studio man-
ages to the FH/FHV sensor via the Ether-
net.
If not connected, right-click the FH/FHV
sensor in the Multiview Explorer and select
Save file from the menu to save the data in
the external memory. Then, load the data
in the external memory to the FH/FHV sen-
sor.
Uploading the set-
tings data for the
FH/FHV sensor
The settings data for the FH/FHV sensor is
not uploaded.
After performing the data uploading to Sys-
mac Studio, all the FH/FHV settings data
values (i.e., the scene group data, the sys-
tem data, the communications command
macros, and the security settings data) that
the FH/FHV sensor manages within the
project data that Sysmac Studio manages
will be reset to the factory defaults.
The device variables related to the FH/FHV
sensor in the I/O Map are uploaded.
There are following two methods to trans-
fer the settings data for the FH/FHV sensor
to Sysmac Studio.
• Directly connecting to the FH/FHV sen-
sor and uploading the data.
• Save the settings data in the FH/FHV
sensor in the external memory and load
it to Sysmac Studio via the external
memory.
Uploading the settings data for the FH/FHV
sensor to Sysmac Studio is possible.
If the FH/FHV sensor is connected to the
computer that runs Sysmac Studio via
Ethernet, loading the data in the FH/FHV
sensor to Sysmac Studio project is possi-
ble by transferring the FH/FHV settings da-
ta to the project via Ethernet.
If not connected, connect the external
memory that holds the FH/FHV settings da-
ta to the computer that runs Sysmac Stu-
dio. Then, right-click the FH/FHV sensor in
the Multiview Explorer and select Load
from file from the menu to load the data.
1 Overview
1 - 6
FH/FHV Series Vision System Operation Manual for Sysmac Studio (Z343-E1)
