Oracle SL150 - Cable the Library and Power on after Installing the Expansion Module; Install the Remaining Expansion Modules

Tip:
When the library capacity is more than 300 cartridges, you will not
connect the output port for Module 6 through Module 10 now. You
connect the port when installing Module 11 through Module 15.
2. Install the tape drive assembly.
See Replace the Drive Tray.
3. Install the tape drive filler.
See Install the Drive Slot Cover.
4. Install the power supply.
See Replace the Power Supply.
5. Install the power supply filler.
See Install a Power Supply Slot Cover.
6. Insert the cartridge magazines.
See Replace the Cartridge Magazines.
Install the Remaining Expansion Modules
Replace modules below the new Expansion Module.
1. Locate the next Expansion Module for installation (refer to the module number
label on the back of the module).
2. Repeat the installation tasks until all Expansion Modules and CRUs are installed.
See Install the Expansion Module Chassis.
See Install CRUs, Fillers, and Magazines in Replaced Module.
3. Make sure you have installed the floor in the bottom module.
See Install the Floor in the Bottom Expansion Module.
Cable the Library and Power On After Installing the Expansion Module
After installing the module, you must reconnect cabling and power on the library.
1. Reconnect all cables.
See Cable the Library.
2. Secure the hook and loop strap to the replaced Expansion Module (close the
plunger of the rivet).
3. Align, dress, and secure cables in the hook and loop straps.
4. Follow the power on procedures.
See Validate the Component Installation.
