Oracle SL150 - Networking and Host Communication; Storage Slot, Mailslot, and Drive Counts for Different Configurations

Table 1-3 Storage Slot, Mailslot, and Drive Counts for Different Configurations
Modules Total Storage
Slots for
Standard Mailslot
Configuration
Total Storage
Slots for
Expanded Mailslot
Configuration
Total Drive
Slots
Base Module 30 15 2
Base Module plus one
Expansion Module (Each
Expansion has 30 storage slots
and 2 drive slots)
60 45 4
Base Module plus two
Expansion Modules
90 75 6
Base Module plus three
Expansion Modules
120 105 8
Base Module plus four
Expansion Modules
150 135 10
Base Module plus five
Expansion Modules
180 165 12
Base Module plus six
Expansion Modules
210 195 14
Base Module plus seven
Expansion Modules
240 225 16
Base Module plus eight
Expansion Modules
270 255 18
Base Module plus nine
Expansion Modules
300 285 20
Base Module plus 10
Expansion Modules
330 315 22
Base Module plus 11
Expansion Modules
360 345 24
Base Module plus 12
Expansion Modules
390 375 26
Base Module plus 13
Expansion Modules
420 405 28
Base Module plus 14
Expansion Modules
450 435 30
Networking and Host Communication
The SL150 supports IPv6. The library has requirements when selecting a switch and
configuring a SAN.
• IPv6 Network Address Support
• Selecting a Switch that Uses Power Over Ethernet (POE)
• Configuring a SAN Connection
