Weights and Dimensions
Size and weight for SL150 library components both packaged for shipping and
unpackaged.
In the tables below:
• Base complete weight includes base chassis, two magazines, robot, one drive,
and one power supply.
• Expansion complete weight includes expansion chassis, two magazines, one
drive, and one power supply.
Table 1-1 Shipping (Packaged) Weights and Dimensions
Component Width Height Depth Weight
Base 63.5 cm (25 in) 40.6 cm (16 in) 115.6 cm (45.5 in) 43 kg (94.8 lbs) for
pallet and complete
weight
28.6 kg (63 lbs) for
pallet and chassis
only
Expansion 61 cm (24 in) 24.8 cm (9.75 in) 113 cm (44.5 in) 15.9 kg (35 lbs) for
complete weight
12.3 kg (27 lbs) for
chassis only
Tape Drive 41.6 cm (16.4 in) 21 cm (8.25 in) 43.8 cm (17.25 in) 3.6 kg (8 lbs)
Power Supply 20.3 cm (8 in) 14.6 cm (5.75 in) 30.5 cm (12 in) 1.6 kg (3.6 lbs)
Robot CRU 47.6 cm (18.75 in) 20.3 cm (8 in) 96.5 cm (38 in) 8.3 kg (18.4 lbs)
Op Panel CRU 24.5 cm (9.6 in) 9.5 cm (3.75 in) 46 cm (18.1 in) 1 kg (2.25 lbs)
Magazine CRU 31.1 cm (12.25 in) 26.4 cm (10.4 in) 73 cm (28.75 in) 3.4 kg (7.5 lbs)
Note:
You can install the SL150 in a rack with front to rear rail spacing from 457
mm (18 inches) to 902 mm (35.5 inches).
Table 1-2 Component (Unpackaged) Weights and Dimensions
Component Width Height Depth Weight
Base 48 cm( 18.9 in) std.
19 in rack
3U (13.34 cm/5.25 in) 92.5 cm (36.4 in) 24.4 kg (53.9 lbs) for
complete weight
13.1 kg (28.9 lbs) for
chassis only
