Table 1-2 (Cont.) Component (Unpackaged) Weights and Dimensions
Component Width Height Depth Weight
Expansion 48 cm( 18.9 in) std.
19 in rack
2U (8.89 cm/3.5 in) 92.5 cm (36.4 in) 12.1 kg (26.7 lbs) for
complete weight
7.5 kg (16.5 lbs)
chassis only
Tape Drive 20.3 cm (8 in) 4.1 cm (1.6 in) 28.4 cm (11.2 in) 2 kg (4.58 lbs)
Power Supply 9.5 cm (3.75 in) 3.2 cm (1.25 in) 22.9 cm (9 in) 0.8 kg (1.82 lbs)
Robot CRU 38.1 cm (15 in) 6.4 cm (2.5 in) 86.9 cm (34.2 in) 5.1 kg (11.18 lbs)
Op Panel CRU 13 cm (5.1 in) 2.5 cm (1 in) 35 cm (13.75 in) 0.4 kg (0.9 lbs)
Magazine CRU 13.7 cm (5.4 in) 8.25 cm (3.25 in) 61.6 cm (24.25 in) 0.9 kg (1.9 lbs)
Power Requirements
Power usage for the SL150 depends on the components installed.
Component Idle (W) Steady State Maximum (W)
Base module (one power supply) 35 38
Expansion module (no power supplies or drives) 1 1
Tape Drive 9 29.5
Additional Power Supply 6 6
For volt-amp (VA) measurements, add 2 percent to the Watt value.
For Btu/hr, multiply the total wattage number by 3.414.
Refer to the power calculator at:
http://www.oracle.com/us/products/servers-storage/sun-power-calculators/
calc/sl150-power-calculator-1954625.html
A minimum library configuration has a total idle power of 44 W (150 Btu/hr) and a
steady state maximum of 67.5 W (230 Btu/hr).
A ten module library with 20 tape drives and 20 power supplies has a total idle power
of 338 W (1154 Btu/hr) and a steady state maximum of 751 W (2564 Btu/hr).
Library Cartridge Capacity
The number of cartridges the library can hold depends on the Base Module hardware
level and software version.
• Hardware level 12 and firmware 3.00+ supports up to 15 modules, 1 to 450 tape
cartridges, and 1 to 30 tape drives.
• Hardware levels up to 11 with firmware 2.6 and below support up to 10 modules, 1
to 300 tape cartridges, and 1 to 20 tape drives.
IMPORTANT: You cannot upgrade older hardware to level 12. You must order a
new library to have hardware level 12.
Chapter 1
Library Specifications
1-8
