Part Type Description Initial Order Part Number Upgrade Part Number
Power Cable Jumper, 1 m, straight
IEC60320-2-2 Sheet E(C14)plug,
right angle IEC60320-1-C13
connector, 10A. 250 VAC
333U-10-10-C14 PWRCORD10187055-Z
Power Cable Argentina, 2.5 m, IRAM207 333A-25-10-AR N/A
Power Cable XATO, PWRCRD, 2.5 meter, Brazil
C13
333A-25-10-BR N/A
Power Cable PWRCORD, CHINA, 2.5 meter,
GB2099, 10A
333A-25-10-CN N/A
Power Cable PWRCORD, ISRAEL, 2.5 meter,
SI-32, 10A
333A-25-10-IL N/A
Power Cable PWRCORD, INDIA, 2.5 meter,
IS1293, 10A
333A-25-10-IN N/A
Power Cable PWRCORD, KOREA, 2.5 meter,
KSC8305, 10A
333A-25-10-KR N/A
Configuration and Ordering Examples
The components you need to order varies based on the library configuration.
Example 1: 30 cartridge library with an IBM LTO-7 FC drive, a second FC drive, and a
second power supply (redundant power):
• 7114334 — Base Module, 30 slots with IBM LTO-7 half-height FC tape drive
• 7114335 — Drive, IBM LTO-7, half-height FC
• 7101769 — Power supply
Example 2: 60 cartridge library with two partitions, a total of four IBM LTO-8 drives (2
SAS and 2 FC), and four power supplies:
• 7118432 — Base Module, 30 slots with one IBM LTO-8 half-height SAS tape drive
• 7101763 — Expansion Module, 30 slots
• 7118438 — Drive, IBM LTO-8, half-height SAS
• 7118437 — Drive, IBM LTO-8, half-height FC (x2)
• 7101769 — Power supply (x3)
Example 3: 90 cartridge library with one IBM LTO-8 FC drive
• 7118433 — Base Module, 30 slots with one IBM LTO-8 half-height FC tape drive
• 7101763 — Expansion Module, 30 slots (x2).
Note that an Expansion Module receives power from the Base Module. The
Expansion Module requires a power supply only when it contains a tape drive.
Example 4: Upgrade an existing library without partitions from 30 to 120 cartridges
with a SAS drive in each module (power is not redundant):
• 7101770 — Expansion Module, 30 slots (x3)
• 7118438 — Drive, IBM LTO-8, half-height SAS (x3)
• 7101771 — Power supply (x3)
Chapter 1
SL150 Marketing Part Numbers
1-15
