These Output Ports: Connect to:
Base Module Output Port 2 Module 2 Controller Input Port
Base Module Output Port 3 Module 3 Controller Input Port
Base Module Output Port 4 Module 4 Controller Input Port
Base Module Output Port 5 Module 5 Controller Input Port
Base Module Output Port 6 Module 6 Controller Input Port
Base Module Output Port 7 Module 7 Controller Input Port
Base Module Output Port 8 Module 8 Controller Input Port
Base Module Output Port 9 Module 9 Controller Input Port
Base Module Output Port 10 Module 10 Controller Input Port
Module 1 thru 5 Controller Output Do not connect anything. Leave dust cover in place.
Module 6 Controller Output Port Module 11 Controller Input Port
Module 7 Controller Output Port Module 12 Controller Input Port
Module 8 Controller Output Port Module 13 Controller Input Port
Module 9 Controller Output Port Module 14 Controller Input Port
Module 10 Controller Output Port Module 15 Controller Input Port
Module 11 thru 15 Controller Output Do not connect to anything. Leave dust cover in place.
