Chapter 4 Settings — [POSITION] menu
120 - ENGLISH
3) Press the <ENTER> button.
f The screen for the selected item is displayed.
4) Press as to select [FREE GRID].
5) Press qw to select [ON].
6) Press the <ENTER> button.
f The [FREE GRID] screen is displayed.
7) Press as to select [INITIALIZE].
8) Press the <ENTER> button.
f The conrmation screen is displayed.
9) Press qw to select [OK], and press the <ENTER> button.
Note
f Each correction data for [KEYSTONE], [CORNER/PINCUSHION], [CURVED CORRECTION], [PC-1], [PC-2], and [PC-3] cannot be
initialized at once.
To initialize all the correction data, select each item and execute [INITIALIZE] individually.
f When the projector is initialized by one of the following methods, all data in [FREE GRID] are initialized.
g When initialized by selecting the [PROJECTOR SETUP] menu → [INITIALIZE] → [FACTORY RESET]
g When initialized by setting the [PROJECTOR SETUP] menu → [INITIALIZE] → [USER SETTINGS] → [OTHER USER SETTING] to
[INITIALIZE]
[CONVERGENCE]
Correct the position shift of the three primary colors of red, green, and blue in the projected image.
1) Press as to select [CONVERGENCE].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] Disables the convergence function.
[ON] Enables the convergence function.
f Proceed to Step 3) when [ON] is selected.
3) Press the <ENTER> button.
f The [CONVERGENCE] screen is displayed.
4) Press as to select the color to adjust, and press the <ENTER> button.
5) Press as to select the position on the projected image to adjust and adjustment direction, and
press qw to adjust.
Note
f The picture quality may degrade when the convergence function is used.
f It is recommended to perform the adjustment with the convergence function after 30 minutes have elapsed with the focus test pattern
displayed. For details of the test pattern, refer to “[TEST PATTERN] menu” (x page 206).
