Panasonic DLP PT-RZ34K

2 - ENGLISH
Contents
Contents
Read this rst! 5
Chapter 1 Preparation
Precautions for use 21
Intended use of the product
21
Installation and handling of the laser product
(for USA and Canada)
21
Cautions when transporting
21
Cautions when installing
21
Cautions when setting up the projector
23
Security
24
Notes regarding the wireless LAN
25
DIGITAL LINK
26
Art-Net
26
Application software supported by the projector
26
Storing
27
Disposal
27
Cautions on use
27
Accessories
28
Optional accessories
29
About your projector
30
Remote control
30
Projector body
32
Names and functions of the Interface Board
(optional)
35
Preparing the remote control
37
Inserting and removing the batteries
37
When using the multiple projectors
37
Connecting the remote control to the projector
with a cable
38
Chapter 2 Getting Started
Setting up 40
Usable outlet
40
Installation mode
40
Projected image and throw distance
41
Adjusting adjustable feet
55
Attaching/removing the projection lens
(optional)
56
Attaching the projection lens
57
Removing the projection lens
58
Connecting 59
Before connecting
59
Connecting example: AV equipment
59
Connecting example: Computers
63
Connecting example using DIGITAL LINK
64
Connecting example when using the
contrast synchronization function/shutter
synchronization function
65
Chapter 3 Basic Operations
Switching on/off the projector 68
Connecting the power cord
68
Power indicator
69
Switching on the projector
70
When the initial setting screen is displayed
71
When the administrator account setting screen
is displayed
76
Making adjustments and selections
77
Switching off the projector
78
Projecting
79
Selecting the input signal
79
Adjusting the focus, zoom, and lens shift
81
Adjusting the focus balance
82
Setting the lens type
84
Executing the lens calibration
85
Moving the projection lens to the home position
86
Lens shift range
88
Adjusting the lens mounter when the focus is
unbalanced
90
Using the USB memory
92
Notes on use
92
USB memory that can be used with the
projector
92
Attaching the USB memory
92
Removing the USB memory
92
Operating with the remote control
93
Using the shutter function
93
Using the on-screen display function
93
Using the automatic setup function
94
Switching the image aspect ratio
94
Using the function button
94
Displaying internal test pattern
95
Using the status function
95
Setting ID number of the remote control
95
