Panasonic DLP PT-RZ34K

Chapter 4 Settings — [DISPLAY OPTION] menu
142 - ENGLISH
[SCREEN FIT] Changes the EDID data according to the [SCREEN FORMAT] setting.
[USER] Sets the [RESOLUTION] and [VERTICAL SCAN FREQUENCY] items to EDID.
f Proceed to Step 10) when [DEFAULT] or [SCREEN FIT] is selected.
6) Press the <ENTER> button.
f The [RESOLUTION] screen is displayed.
7) Press asqw to select [RESOLUTION].
f Select [1024x768p], [1280x720p], [1280x800p], [1280x1024p], [1366x768p], [1400x1050p], [1440x900p],
[1600x900p], [1600x1200p], [1680x1050p], [1920x1080p], [1920x1080i], or [1920x1200p].
8) Press the <ENTER> button.
f The [VERTICAL SCAN FREQUENCY] screen is displayed.
9) Press qw to select [VERTICAL SCAN FREQUENCY].
f Select [60Hz], [50Hz], [30Hz], [25Hz], or [24Hz] when [1920x1080p] is selected for [RESOLUTION].
f Select [60Hz], [50Hz], or [48Hz] when [1920x1080i] is selected for [RESOLUTION].
f Select [60Hz] or [50Hz] when anything other than following is selected for [RESOLUTION].
g [1920x1080p], [1920x1080i]
10) Press the <ENTER> button.
f The conrmation screen is displayed.
11) Press qw to select [OK], and press the <ENTER> button.
Note
f The settings in [RESOLUTION] and [VERTICAL SCAN FREQUENCY] are displayed in [EDID STATUS].
f The resolution and vertical scanning frequency settings may also be required on your computer or video device.
f The computer, video device, or projector in use may require the power to be turned off and on again after conguring settings.
f A signal may not be output with the resolution and vertical scanning frequency that have been set, depending on your computer or video
device.
[SDI IN]
Set this item in accordance with the signal input to the <SDI IN> terminal.
Setting [RESOLUTION] in [SDI IN]
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [RESOLUTION], and press the <ENTER> button.
f The [RESOLUTION] screen is displayed.
4) Press as to select an item, and press the <ENTER> button.
f Select [AUTO], [1280x720p], [1920x1080i], [1920x1080p], [1920x1080sF], or [2048x1080p].
Setting [3G-SDI MAPPING] in [SDI IN]
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [3G-SDI MAPPING].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically selects [LEVEL A] or [LEVEL B].
[LEVEL A] Fixes the mapping method to 3G-SDI Level-A.
[LEVEL B] Fixes the mapping method to 3G-SDI Level-B.
