Chapter 4 Settings — [PROJECTOR SETUP] menu
198 - ENGLISH
[SYSTEM SELECTOR]
Switches the [SYSTEM SELECTOR] setting according to the input signal of the image being
projected.
f When the input is SDI1 to SDI4 on the Interface Board
g The [DISPLAY OPTION] menu → [SLOT IN] → [SINGLE LINK SETTING] → [SDI1]/[SDI2]/
[SDI3]/[SDI4] → [SYSTEM SELECTOR]
g The [DISPLAY OPTION] menu → [SLOT IN] → [DUAL LINK SETTING] → [SYSTEM
SELECTOR]
f When the input is SDI OPT1 or SDI OPT2 on the Interface Board
g The [DISPLAY OPTION] menu → [SLOT IN] → [SDI OPT1]/[SDI OPT2] → [SYSTEM
SELECTOR]
f When the input is anything other than SDI/SDI OPT
The [PICTURE] menu → [SYSTEM SELECTOR]
[SYSTEM DAYLIGHT VIEW]
Switches the [SYSTEM DAYLIGHT VIEW] setting. (x page 109)
[FREEZE]
Temporarily pauses the image. (x page 165)
[WAVEFORM MONITOR]
Displays the waveform of the input signal. (x page 165)
[LENS MEMORY LOAD]
Loads the registered lens memory. (x page 170)
[LEFT/RIGHT SWAP]
Switches the [LEFT/RIGHT SWAP] setting. (x page 130)
[PROJECTION METHOD]
Switches the [PROJECTION METHOD] setting. (x page 167)
[GEOMETRY]
Switches the [GEOMETRY] setting. (x page 115)
[OSD POSITION]
Switches the [OSD POSITION] setting. (x page 158)
4) Press the <ENTER> button.
Note
f The [FUNCTION BUTTON] screen can also be displayed by holding down the <FUNCTION> button on the remote control.
[STATUS]
Display the status of the projector.
1) Press as to select [STATUS].
2) Press the <ENTER> button.
f The [STATUS] screen is displayed.
3) Press qw to switch the pages.
f The page will change each time you press the button.
[PROJECTOR TYPE] Displays the type of the projector.
[SERIAL NUMBER] Displays the serial number of the projector.
[PROJECTOR RUNTIME] Displays the runtime of the projector.
[LIGHT RUNTIME] Displays the runtime of the light source.
[CONTINUOUS LIGHTING
TIME]
Displays the elapsed time from when the light source is illuminated.
The elapsed time after the illumination of the light source can be conrmed when adjusting the focus.
The elapsed time is reset when the light source is temporarily turned off such as using the shutter
function.
[MAIN/SUB VERSION] Displays the main and sub versions of the rmware of the projector.
[NETWORK VERSION] Displays the network version of the rmware of the projector.
[INTAKE AIR TEMP.]
*1
Displays the intake air temperature status.
[EXHAUST AIR TEMP.]
*1
Displays the exhaust air temperature status.
[SELF TEST] Displays the self-diagnosis information.
[INPUT]
Displays the input terminal currently selected.
Displays the representative input terminal when one image is displayed with multiple input signals.
[SIGNAL NAME] Displays the input signal name.
[MEMORY NO.] Displays the memory number of the input signal.
[BACKUP INPUT STATUS]
Displays whether switching to the backup input signal is possible or not when [BACKUP INPUT
MODE] is set to [OFF]. (x page 137)
[NUMBER OF REGISTERED
SIGNAL]
Displays the number of registered signals.
[COOLING CONDITION] Displays the set cooling conditions.
[ATMOSPHERIC PRESSURE] Displays the atmospheric pressure.
[REMOTE2 STATUS] Displays the control status of the REMOTE2.
[AC VOLTAGE] Displays the input supply voltage.
To Next Page
