rProjection in all 360° direction is possible.
360°
360°
360°
360° vertically 360° horizontally 360° tilted
(combination of vertical and horizontal)
Cautions when setting up the projector
f Install the projector in a place or with a mount that can sufciently tolerate the weight. The position of the
projected image may shift if the strength is not sufcient.
f Use the adjustable feet only for the oor standing installation and for adjusting the angle. Using them for other
purposes may damage the projector.
f The adjustable feet can be removed if not needed in the installation. However, do not use the screw holes
where the adjustable feet were removed for any other purpose such as xing the projector to a mount.
f When installing and using the projector in a method other than the oor installation using the adjustable feet,
remove the adjustable feet (4 locations) and use the six screw holes to x the projector to a mount (as shown in
the gure).
In such case, make sure that there is no clearance between the screw holes for ceiling mount on the projector
bottom and the setting surface by inserting spacers (metallic) between them.
f Use a torque screwdriver or Allen torque wrench to tighten the xing screws to their specied tightening torques.
Do not use electric screwdrivers or impact screwdrivers.
For the screws to x the projector, use commercially available ISO 898-1 standard screws (made of carbon steel
or alloy steel).
(Screw diameter: M6, tapping depth inside the projector: 27 mm (1-1/16"), screw tightening torque: 4 ± 0.5 N·m)
Positions of screw holes to fix projector and
adjustable feet
Adjustable feet
27 (1-1/16")
Mount
M6
Thread engagement depth
Screw holes to fix the projector
Unit: mm
Adjustable feet
