Panasonic DLP PT-RZ34K

Chapter 7 Appendix — Specications
ENGLISH - 309
List of compatible signals
The following table species the video signals that the projector can project.
For details of DisplayPort signal, refer to “List of DisplayPort compatible signals” (x page 313).
For details of SDI signal, refer to “List of single link SDI compatible signals” (x page 314), “List of dual link SDI
compatible signals” (x page 317).
This projector supports the signal with l in the compatible signal column.
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock freq.
(MHz)
Compatible signal
Horizontal
(kHz)
Vertical
(Hz)
DIGITAL
LINK
HDMI DVI-D
480/60p 720 x 480 31.5 59.9 27.0
l l l
576/50p 720 x 576 31.3 50.0 27.0
l l l
720/60p 1 280 x 720 45.0 60.0
*1
74.3
l l l
720/50p 1 280 x 720 37.5 50.0 74.3
l l l
720/120p 1 280 x 720 90.0 120.0
*1
148.5
l l
―
1080/60i 1 920 x 1 080i 33.8 60.0
*1
74.3
l l l
1080/50i 1 920 x 1 080i 28.1 50.0 74.3
l l l
1080/24p 1 920 x 1 080 27.0 24.0
*1
74.3
l l l
1080/24sF 1 920 x 1 080i 27.0 48.0
*1
74.3
l l l
1080/25p 1 920 x 1 080 28.1 25.0 74.3
l l l
1080/30p 1 920 x 1 080 33.8 30.0
*1
74.3
l l l
1080/60p 1 920 x 1 080 67.5 60.0
*1
148.5
l l l
1080/50p 1 920 x 1 080 56.3 50.0 148.5
l l l
1080/120p 1 920 x 1 080 135.0 120.0
*1
297.0
l l
―
3840 x 2160/24p 3 840 x 2 160 54.0 24.0
*1
297.0
l l
―
3840 x 2160/25p 3 840 x 2 160 56.3 25.0 297.0
l l
―
3840 x 2160/30p 3 840 x 2 160 67.5 30.0
*1
297.0
l l
―
3840 x 2160/60p
3 840 x 2 160 135.0 60.0
*1
297.0
l
*2
l
*2
―
3 840 x 2 160 135.0 60.0
*1
594.0 ―
l
―
3840 x 2160/50p
3 840 x 2 160 112.5 50.0 297.0
l
*2
l
*2
―
3 840 x 2 160 112.5 50.0 594.0 ―
l
―
4096 x 2160/24p 4 096 x 2 160 54.0 24.0
*1
297.0
l l
―
4096 x 2160/25p 4 096 x 2 160 56.3 25.0 297.0
l l
―
4096 x 2160/30p 4 096 x 2 160 67.5 30.0
*1
297.0
l l
―
4096 x 2160/60p
4 096 x 2 160 135.0 60.0
*1
297.0
l
*2
l
*2
―
4 096 x 2 160 135.0 60.0
*1
594.0 ―
l
―
4096 x 2160/50p
4 096 x 2 160 112.5 50.0 297.0
l
*2
l
*2
―
4 096 x 2 160 112.5 50.0 594.0 ―
l
―
640 x 480/60 640 x 480 31.5 59.9 25.2
l l l
1024 x 768/50 1 024 x 768 39.6 50.0 51.9
l l l
1024 x 768/60 1 024 x 768 48.4 60.0 65.0
l l l
1280 x 800/50 1 280 x 800 41.3 50.0 68.0
l l l
1280 x 800/60 1 280 x 800 49.7 59.8 83.5
l l l
1280 x 1024/50 1 280 x 1 024 52.4 50.0 88.0
l l l
1280 x 1024/60 1 280 x 1 024 64.0 60.0 108.0
l l l
1366 x 768/50 1 366 x 768 39.6 49.9 69.0
l l l
1366 x 768/60 1 366 x 768 47.7 59.8 85.5
l l l
1400 x 1050/50 1 400 x 1 050 54.1 50.0 99.9
l l l
1400 x 1050/60 1 400 x 1 050 65.2 60.0 122.6
l l l
1440 x 900/50 1 440 x 900 46.3 49.9 86.8
l l l
1440 x 900/60 1 440 x 900 55.9 59.9 106.5
l l l
1600 x 900/50 1 600 x 900 46.4 49.9 96.5
l l l
1600 x 900/60 1 600 x 900 55.9 60.0 119.0
l l l
1600 x 1200/50 1 600 x 1 200 61.8 49.9 131.5
l l l
1600 x 1200/60 1 600 x 1 200 75.0 60.0 162.0
l l l
1680 x 1050/50 1 680 x 1 050 54.1 50.0
119.5
l l l
1680 x 1050/60 1 680 x 1 050 65.3 60.0 146.3
l l l
