Chapter 4 Settings — [TEST PATTERN] menu
206 - ENGLISH
[TEST PATTERN] menu
On the menu screen, select [TEST PATTERN] from the main menu.
Refer to “Navigating through the menu” (x page 98) for the operation of the menu screen.
[TEST PATTERN]
Display the test pattern built-in to the projector.
Settings of position, size, and other factors will not be reected in test patterns. Make sure to display the input
signal before performing various adjustments.
1) Press qw to switch the [TEST PATTERN] item.
f The items will switch each time you press the button.
Menu screen + All white
Displays a test pattern with the menu screen. Select a desired test pattern.
Menu screen + All black
Menu screen + Window
Menu screen + Window
(inversion)
Menu screen + Color bar
(vertical)
Menu screen + Color bar
(horizontal)
Menu screen + 16:9/4:3
aspect frame
Menu screen + Circle
Menu screen + Cross hatch
Menu screen + Focus
Menu screen + Input screen
Displays the menu screen and input signal.
Built-in test patterns are not displayed.
Note
f Press the <ON SCREEN> button on the remote control while the test pattern is displayed to hide the menu screen.
f It is recommended to perform the focus adjustment after 30 minutes have elapsed with the focus test pattern displayed. To use the active
focus optimizer function, set the [PROJECTOR SETUP] menu → [LENS] → [ACTIVE FOCUS OPTIMIZER] → [ACTIVE FOCUS] to [ON],
and then adjust the focus. (x page 173)
Changing the color of the cross hatch test pattern
The color can be changed when the “Menu screen + Cross hatch” test pattern is displayed.
1) Press qw to select the “Menu screen + Cross hatch” test pattern.
2) Press the <ENTER> button.
f The [TEST PATTERN COLOR] screen is displayed.
3) Press as to select a color, and press the <ENTER> button.
f The color of the cross hatch test pattern is changed to the selected color.
Note
f The test pattern color settings return to [WHITE] when the projector is switched off.
f Colors of the test patterns other than cross hatch test patterns cannot be changed.
