Chapter 4 Settings — [NETWORK] menu
214 - ENGLISH
[NETWORK] menu
On the menu screen, select [NETWORK] from the main menu, and select an item from the sub-menu.
Refer to “Navigating through the menu” (x page 98) for the operation of the menu screen.
[ETHERNET TYPE]
Set the transmission path of the Ethernet signal.
1) Press as to select [ETHERNET TYPE].
2) Press the <ENTER> button.
f The [ETHERNET TYPE] screen is displayed.
3) Press as to select an item.
[LAN] Select this item when using only the <LAN> terminal to transmit the Ethernet signal.
[DIGITAL LINK] Select this item when using only the <DIGITAL LINK> terminal to transmit the Ethernet signal.
[LAN & DIGITAL LINK]
Select this item when using the <DIGITAL LINK> terminal and the <LAN> terminal to transmit the
Ethernet signal.
4) Press the <ENTER> button.
Note
f When [ETHERNET TYPE] is set to [LAN], the Ethernet and serial control signals cannot be transmitted via the optional DIGITAL LINK output
supported device (Model No.: ET-YFB100G, ET-YFB200G) connected to the <DIGITAL LINK> terminal.
f The <DIGITAL LINK> terminal and the <LAN> terminal are connected inside of the projector when [ETHERNET TYPE] is set to [LAN &
DIGITAL LINK]. Do not directly connect the <DIGITAL LINK> terminal and the <LAN> terminal using a LAN cable. Construct the system so
that it is not connected to the same network via the peripherals such as the hub or the twisted-pair-cable transmitter.
[DIGITAL LINK]
Perform the setting and operation regarding the DIGITAL LINK.
[DIGITAL LINK MODE]
Switch the communication method of the <DIGITAL LINK> terminal of the projector.
1) Press as to select [DIGITAL LINK].
2) Press the <ENTER> button.
f The [DIGITAL LINK] screen is displayed.
3) Press as to select [DIGITAL LINK MODE].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Switches the communication method automatically to DIGITAL LINK, long reach, or Ethernet.
[DIGITAL LINK] Fixes the communication method to DIGITAL LINK.
[LONG REACH] Fixes the communication method to long reach.
[ETHERNET] Fixes the communication method to Ethernet.
r Possible communication modes
l: Communication possible
―: Communication not possible
Setting
Communication possible
Video transfer
(100 m (328'1"))
Video transfer
(150 m (492'2"))
Ethernet RS-232C
[AUTO]
For DIGITAL LINK
l
―
l l
For long reach ―
l l l
For Ethernet ― ―
l
*1
―
[DIGITAL LINK]
l
―
l l
