Chapter 5 Operations — Using the information monitor function
262 - ENGLISH
Basic operation procedure in the menu operation mode
1) Press the <INFO> button on the control panel.
f The top menu screen is displayed.
USER VIEW
SETUP
STATUS
2) Press as to select a top menu item.
f The selected item is displayed inverted.
USER VIEW
SETUP
STATUS
3) Press the <ENTER> button.
f The sub-menu for the selected top menu is displayed.
ID
INFO MONITOR
NETWORK
4) Press as to select a sub-menu item, and press the <ENTER> button.
f The setting screen is displayed.
5) Press qw to change the setting.
Note
f Pressing the <INFO> button during the menu operation mode returns to the previous menu screen.
f Information monitor will transfer to the hide mode/USER VIEW mode automatically if there is no operation for approximately 60 seconds
during the menu operation mode. Pressing the <INFO> button on the control panel returns to the original menu operation mode display.
[USER VIEW] menu
Set the information monitor to the menu operation mode by pressing the <INFO> button on the control panel.
For the operation of the menu, refer to “Basic operation procedure in the menu operation mode” (x page 262).
[USER VIEW]
Display the basic information of the projector.
1) Press as to select [USER VIEW].
2) Press the <ENTER> button.
f The information is displayed.
3) Press as to switch the pages.
f The page will change each time you press the button.
[INPUT] Currently selected input terminal
*1
[SIGNAL NAME] Input signal name
[AC VOLTAGE] Input supply voltage
[INTAKE AIR TEMP.] Intake air temperature of the projector
[EXHAUST AIR TEMP.] Exhaust air temperature of the projector
