Panasonic DLP PT-RZ34K

Chapter 7 Appendix — Technical information
ENGLISH - 293
Using Art-Net function
Since the network function of the projector supports the Art-Net function, you can control the projector settings
with the DMX controller and application software using the Art-Net protocol.
Note
f To use the Art-Net function with the projector, it is necessary to set the password of the administrator account. (x page 220)
Channel denition
The following table lists the channel denitions used for controlling the projector with the Art-Net function.
Channel settings can be switched using the [NETWORK] menu → [Art-Net] → [Art-Net CHANNEL SETTING]
(x page 223).
The control details assigned to each channel are listed in the following table.
f Channel assignment for [USER] is in factory default setting. Assignment can be changed.
Channel
Control details
[1] [2] [3] [USER]
CHANNEL1 SHUTTER LIGHT OUTPUT LIGHT OUTPUT LIGHT OUTPUT
CHANNEL2 INPUT SELECT INPUT SELECT INPUT SELECT INPUT SELECT
CHANNEL3
LENS FUNCTION
SELECT
LENS POSITION LENS POSITION LENS POSITION
CHANNEL4 LENS CONTROL LENS H SHIFT LENS H SHIFT LENS H SHIFT
CHANNEL5 POWER LENS V SHIFT LENS V SHIFT LENS V SHIFT
CHANNEL6 LIGHT OUTPUT LENS FOCUS LENS FOCUS MSB LENS FOCUS
CHANNEL7 ENABLE/DISABLE LENS ZOOM LENS FOCUS LSB LENS ZOOM
CHANNEL8 FADE-IN POWER LENS ZOOM MSB POWER
CHANNEL9 FADE-OUT GEOMETRY LENS ZOOM LSB GEOMETRY
CHANNEL10 CUSTOM MASKING CUSTOM MASKING SHUTTER CUSTOM MASKING
CHANNEL11 GEOMETRY ENABLE/DISABLE ENABLE/DISABLE ENABLE/DISABLE
CHANNEL12 NONE NONE NONE NONE
Content that can be controlled by each Art-Net channel setting
l: Can be controlled
Control details
Art-Net channel setting
[1] [2] [3] [USER]
LIGHT OUTPUT
l l l l
INPUT SELECT
l l l l
LENS FUNCTION SELECT
l
― ― ―
LENS CONTROL
l
― ― ―
LENS POSITION ―
l l l
LENS H SHIFT ―
l l l
LENS V SHIFT ―
l l l
LENS FOCUS ―
l
―
l
LENS ZOOM ―
l
―
l
POWER
l l
―
l
SHUTTER
l
―
l l
FADE-IN
l
― ―
l
FADE-OUT
l
― ―
l
GEOMETRY
l l
―
l
CUSTOM MASKING
l l
―
l
FREEZE ― ― ―
l
COLOR ― ― ―
l
TINT ― ― ―
l
RASTER PATTERN ― ― ―
l
LENS H SHIFT MSB ― ― ―
l
*1
LENS H SHIFT LSB ― ― ―
l
*1
LENS V SHIFT MSB ― ― ―
l
*1
