Panasonic DLP PT-RZ34K

Chapter 7 Appendix — Technical information
294 - ENGLISH
Control details
Art-Net channel setting
[1] [2] [3] [USER]
LENS V SHIFT LSB ― ― ―
l
*1
LENS FOCUS MSB ― ―
l l
*1
LENS FOCUS LSB ― ―
l l
*1
LENS ZOOM MSB ― ―
l l
*1
LENS ZOOM LSB ― ―
l l
*1
ENABLE/DISABLE
l l l l
*1 These items can be controlled in following case.
When the standard DC motor unit installed in the Zoom Lens (Model No.: ET-D75LE6, ET-D75LE8, ET-D75LE10, ET-D75LE20, ET-D75LE30,
ET-D75LE40) is replaced with the stepping motor unit using the Stepping Motor Kit (Model No.: ET-D75MKS10), or when a projection lens with the
stepping motor is attached.
Control details
r LIGHT OUTPUT
This can be set in 256 steps between 100 % and 0 %.
Performance Parameter Default value
100 % 0
0… …
0 % 255
r INPUT SELECT (when [Art-Net CHANNEL SETTING] is set to [1])
Performance Parameter Default value
No operation 0-31
0
DVI-D 32-39
HDMI 40-47
SDI 48-55
No operation 56-255
r INPUT SELECT (when [Art-Net CHANNEL SETTING] is set to anything other than [1])
Performance Parameter Default value
No operation 0-23
0
DVI-D 24-31
HDMI 32-39
DIGITAL LINK 40-47
SDI 48-55
No operation 56-79
SLOT-1
*1
80-87
SLOT-2
*1
88-95
No operation 96-151
SLOT-1
*2
152-159
SLOT-2
*2
160-167
SLOT-3
*2
168-175
SLOT-4
*2
176-183
No operation 184-255
*1 When the Interface Board equipped with two inputs is installed in <SLOT>, the input is switched to the specied input of the Interface Board.
*2 When the Interface Board equipped with four inputs is installed in <SLOT>, the input is switched to the specied input of the Interface Board.
