Panasonic DLP PT-RZ34K

Chapter 4 Settings — [DISPLAY OPTION] menu
ENGLISH - 143
Note
f This function does not operate when the HD-SDI signal is input.
Setting [SYSTEM SELECTOR] in [SDI IN]
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [SYSTEM SELECTOR].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO]
Automatically selects [RGB], [YP
B
P
R
4:4:4], or [YP
B
P
R
4:2:2].
[RGB], [YP
B
P
R
4:4:4], or [YP
B
P
R
4:2:2] is automatically selected by reading the payload ID attached to
the input signal. [RGB] is selected when the payload ID is not attached to the input signal.
[RGB] Fixes to [RGB].
[YP
B
P
R
4:4:4] Fixes to [YP
B
P
R
4:4:4].
[YP
B
P
R
4:2:2] Fixes to [YP
B
P
R
4:2:2].
Setting [BIT DEPTH] in [SDI IN]
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [BIT DEPTH].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically selects [12-bit] or [10-bit].
[12-bit] Fixes to [12-bit].
[10-bit] Fixes to [10-bit].
Setting [SIGNAL LEVEL] in [SDI IN]
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [SIGNAL LEVEL].
4) Press qw to switch the item.
f The items will switch each time you press the button.
[64-940] Normally use this setting.
[4-1019] Select this item when gray is displayed as black.
[DIGITAL LINK IN]
Set this item in accordance with the video signal input to the <DIGITAL LINK> terminal.
Setting [SIGNAL LEVEL] in [DIGITAL LINK IN]
1) Press as to select [DIGITAL LINK IN].
