Panasonic DLP PT-RZ34K

Chapter 4 Settings — [DISPLAY OPTION] menu
156 - ENGLISH
Setting [BIT DEPTH] in [SLOT IN] (SDI input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SINGLE LINK SETTING] or [DUAL LINK SETTING], and press the <ENTER>
button.
f The [SINGLE LINK SETTING] screen or the [DUAL LINK SETTING] screen is displayed.
f Proceed to Step 5) when [DUAL LINK SETTING] is selected.
4) Press as to select [SDI1], [SDI2], [SDI3], or [SDI4], and press the <ENTER> button.
f The [SINGLE LINK SETTING] screen for the selected item is displayed.
5) Press as to select [BIT DEPTH].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO] Automatically selects [12-bit] or [10-bit].
[12-bit] Fixes to [12-bit].
[10-bit] Fixes to [10-bit].
Setting [SIGNAL LEVEL] in [SLOT IN] (SDI input)
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SINGLE LINK SETTING] or [DUAL LINK SETTING], and press the <ENTER>
button.
f The [SINGLE LINK SETTING] screen or the [DUAL LINK SETTING] screen is displayed.
f Proceed to Step 5) when [DUAL LINK SETTING] is selected.
4) Press as to select [SDI1], [SDI2], [SDI3], or [SDI4], and press the <ENTER> button.
f The [SINGLE LINK SETTING] screen for the selected item is displayed.
5) Press as to select [SIGNAL LEVEL].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[64-940] Normally use this setting.
[4-1019] Select this item when gray is displayed as black.
When the optional Interface Board for 12G-SDI Optical (Model No.: ET-MDNFB10) is installed
Set this item according to the input and output signals when this Interface Board is installed in the slot.
Setting [SDI OPT 1/2 OUT] in [SLOT IN] (OPT input)
Set whether or not to output the signal from the <SDI OPT 1/2 OUT> terminal.
1) Press as to select [SLOT IN].
2) Press the <ENTER> button.
f The [SLOT IN] screen is displayed.
3) Press as to select [SDI OPT 1/2 OUT].
4) Press qw to switch the item.
f The items will switch each time you press the button.
