Panasonic DLP PT-RZ34K

Chapter 4 Settings — [PROJECTOR SETUP] menu
200 - ENGLISH
[TOTAL LINES] Displays the total line count of the input signal.
[DISPLAY LINES] Displays the number of input signal display lines.
[SAMPLING] Displays the sampling information and the color format of the input signal.
[BIT DEPTH] Displays the gradation of the input signal.
[SIGNAL LEVEL] Displays the signal level of the input signal.
[COLORIMETRY]
Displays the color gamut information of the input signal. The content of display is as follows.
[ITU-2020]: When the color gamut is compliant with ITU-R BT.2020 standard
[ITU-709]: When the color gamut is compliant with ITU-R BT.709 standard
[SMPTE 170M]: When the color gamut is compliant with SMPTE 170M standard
[---]: When there is no signal, when the color gamut information is not included in the InfoFrame
information, or when the color gamut information other than [ITU-2020], [ITU-709], or [SMPTE 170M] is
included
[HDCP STATUS]
Displays the HDCP status of the input signal. The content of display is as follows.
[HDCP2.2]: When protected with HDCP 2.2
[HDCP1.X]: When protected with HDCP 1.X
[NONE]: When not protected with HDCP
[---]: When there is no signal
r [CONTENT INFORMATION]
[EOTF]
Displays EOTF (Electro-Optical Transfer Function) out of the InfoFrame information added to the input
signal.
[MASTERING DISPLAY
COLOR VOLUME]
[RED]
Displays the chromaticity coordinates for the primary color red out of the
InfoFrame information added to the input signal.
[GREEN]
Displays the chromaticity coordinates for the primary color green out of
the InfoFrame information added to the input signal.
[BLUE]
Displays the chromaticity coordinates for the primary color blue out of the
InfoFrame information added to the input signal.
[WHITE]
Displays the chromaticity coordinates for the white point out of the
InfoFrame information added to the input signal.
[MAX LUMINANCE]
Displays the maximum brightness out of the InfoFrame information added
to the input signal.
[MIN LUMINANCE]
Displays the minimum brightness out of the InfoFrame information added
to the input signal.
[CONTENT LIGHT LEVEL]
[MaxCLL]
Displays MaxCLL (Maximum Content Light Level) out of the InfoFrame
information added to the input signal.
[MaxFALL]
Displays MaxFALL (Maximum Frame Average Light Level) out of the
InfoFrame information added to the input signal.
Note
f If you press the <ENTER> button while displaying [SIGNAL INFORMATION] in the page 6/6 of the [STATUS] screen, the [DETAILED
INFORMATION] screen can be displayed to view the detailed information of the input signal. Information for multiple input signals may be
displayed depending on the projected image. Press qw to switch pages.
f While the [DETAILED INFORMATION] screen is displayed, press the <ENTER> button to display the [CONTENT INFORMATION] screen,
and the contents of the InfoFrame information added to the input signal can be displayed.
f There are items that are displayed or not displayed in [SIGNAL INFORMATION], [DETAILED INFORMATION], and [CONTENT
INFORMATION] depending on the setting and the signal being input.
f While the [STATUS] screen is displayed, press the <DEFAULT> button to check the details of the temperature information of each part
inside the projector.
For details of operation, refer to “Displaying the details of the temperature information” (x page 200).
f If any abnormality has occurred on the projector, press the <DEFAULT> button while the [STATUS] screen is displayed to check the details
of the error information.
f For details on the contents displayed in [SELF TEST], refer to “Self-diagnosis display” (x page 288).
Displaying the details of the temperature information
Details of the temperature information of each part inside the projector can be checked.
1) Press the <DEFAULT> button while the [STATUS] screen is displayed.
f The selection screen is displayed.
2) Press as to select [TEMPERATURE INFORMATION].
f The items will switch each time you press the button.
[ERROR INFORMATION] Displays the detailed screen of the error information.
[TEMPERATURE
INFORMATION]
Displays the detailed screen of the temperature information.
