Panasonic DLP PT-RZ34K

Chapter 4 Settings — [NETWORK] menu
224 - ENGLISH
[3]
*1
Uses the channel assignment with the setting that can numerically control the lens position.
[USER] Changes the channel assignment.
[1]
Uses the channel assignment with DZ21K series compatible.
DZ21K series: DZ21K series, DS20K series, DW17K series, DZ16K series
*1 This item can be selected in the following case.
When the standard DC motor unit installed in the Zoom Lens (Model No.: ET-D75LE6, ET-D75LE8, ET-D75LE10, ET-D75LE20, ET-D75LE30,
ET-D75LE40) is replaced with the stepping motor unit using the Stepping Motor Kit (Model No.: ET-D75MKS10), or when a projection lens
with the stepping motor is attached.
f Proceed to Step 6) when anything other than [USER] is selected. The function assigned to the channel is
displayed by pressing the <ENTER> button.
f Proceed to Step 5) when [USER] is selected.
5) Press the <ENTER> button.
f The [Art-Net CHANNEL SETTING] screen is displayed.
6) Press as to select the channel to set, and pressqw to switch the item.
[LIGHT OUTPUT] Adjusts the amount of light.
[INPUT SELECT] Switches the input.
[LENS POSITION] Moves the lens position.
[LENS H SHIFT] Adjusts the lens shift in the horizontal direction.
[LENS V SHIFT] Adjusts the lens shift in the vertical direction.
[LENS FOCUS] Adjusts the focus.
[LENS ZOOM] Adjusts the zoom.
[POWER] Controls the power status.
[SHUTTER] Controls the shutter.
[FADE-IN] Sets the fade-in time.
[FADE-OUT] Sets the fade-out time.
[GEOMETRY] Performs geometric adjustment.
[CUSTOM MASKING] Performs geometric adjustment using a computer.
[FREEZE] Freezes the projected image.
[COLOR] Adjusts the color saturation.
[TINT] Adjusts the tint.
[RASTER PATTERN] Displays the raster pattern.
[LENS H SHIFT MSB]
*1
Coarsely adjusts the horizontal position of the lens.
[LENS H SHIFT LSB]
*1
Finely adjusts the horizontal position of the lens.
[LENS V SHIFT MSB]
*1
Coarsely adjusts the vertical position of the lens.
[LENS V SHIFT LSB]
*1
Finely adjusts the vertical position of the lens.
[LENS FOCUS MSB]
*1
Coarsely adjusts the focus position of the lens.
[LENS FOCUS LSB]
*1
Finely adjusts the focus position of the lens.
[LENS ZOOM MSB]
*1
Coarsely adjusts the zoom position of the lens.
[LENS ZOOM LSB]
*1
Finely adjusts the zoom position of the lens.
[ENABLE/DISABLE] Enables/disables the control of the projector with the Art-Net function.
[NONE] No denition
*1 These items can be selected in following case.
When the standard DC motor unit installed in the Zoom Lens (Model No.: ET-D75LE6, ET-D75LE8, ET-D75LE10, ET-D75LE20, ET-D75LE30,
ET-D75LE40) is replaced with the stepping motor unit using the Stepping Motor Kit (Model No.: ET-D75MKS10), or when a projection lens
with the stepping motor is attached.
f The setting can be also made by pressing as to select the channel, pressing the <ENTER> button to
display the item list, pressing asqw to select the item, and pressing the <ENTER> button.
f Same item cannot be set for multiple channels, except for [NONE].
Note
f Assign each item of [LENS H SHIFT MSB], [LENS V SHIFT MSB], [LENS FOCUS MSB], and [LENS ZOOM MSB] to a channel together
with [LENS H SHIFT LSB], [LENS V SHIFT LSB], [LENS FOCUS LSB], and [LENS ZOOM LSB]. These cannot be used when assigned to a
channel by itself.
f Assign each item of [LENS H SHIFT LSB], [LENS V SHIFT LSB], [LENS FOCUS LSB], and [LENS ZOOM LSB] to a channel together with
[LENS H SHIFT MSB], [LENS V SHIFT MSB], [LENS FOCUS MSB], and [LENS ZOOM MSB]. These cannot be used when assigned to a
channel by itself.
f MSB: Most Signicant Byte
f LSB: Least Signicant Byte
