Panasonic DLP PT-RZ34K - Page 243

Chapter 5 Operations — Web control function
ENGLISH - 243
Lens position setting page
Click [Projector control] → [Detail control] → [LENS] → [SET POSITION].
4
3
2
1
1 [Get]
Acquires the current lens position and displays the acquired
values in the lens position information eld.
2 Lens position information eld
Enter the lens position (vertical position, horizontal position,
focus position, and zoom position).
3 [Back]
Returns to the [LENS] page.
4 [Apply]
Moves to the lens position displayed in the lens position
information eld.
Note
f The zoom position is displayed in the lens position information eld only in following case.
g When the standard DC motor unit installed in the Zoom Lens (Model No.: ET-D75LE6, ET-D75LE8, ET-D75LE10, ET-D75LE20,
ET-D75LE30, ET-D75LE40) is replaced with the stepping motor unit using the Stepping Motor Kit (Model No.: ET-D75MKS10), or when a
projection lens with the stepping motor is attached.
[Network cong] page
Click [Detailed set up] → [Network cong].
1) Click [Network config].
f Click [Network cong] to display the [CAUTION!] screen.
2) Select the item to change the setting.
f The [WIRELESS LAN] setting can be selected only when the optional Wireless Module (Model No.:
AJ-WM50 Series) is attached.
3) Click [Next].
f The current settings are displayed.
4) Click [Change].
f The setting change screen is displayed.
