Chapter 2 Getting Started — Setting up
50 - ENGLISH
Lens type Fixed-focus Lens
Projection lens Model No. ET-D75LE95
*1
Throw ratio
*2
0.364:1
Projected image size
Projection
distance
(L1)
Distance from the
projector to the screen
Diagonal (SD)
Height
(SH)
Width (SW) (L4) (A1)
1.78 (70") 0.942 1.508 ― ― ―
2.03 (80") 1.077 1.723 ― ― ―
2.29 (90") 1.212 1.939 ― ― ―
2.54 (100") 1.346 2.154 ― ― ―
3.05 (120") 1.615 2.585 0.94
- 0.07 0.17-0.33
3.81 (150") 2.019 3.231 1.18 0.16 0.24-0.44
5.08 (200") 2.692 4.308 1.56 0.54 0.37-0.63
6.35 (250") 3.365 5.385 1.95 0.93 0.49-0.82
7.62 (300") 4.039 6.462 2.33 1.31 0.62-1.02
8.89 (350") 4.712 7.539 2.72 1.70 0.74-1.21
10.16 (400") 5.385 8.616 3.10 2.08 0.86-1.40
12.70 (500") 6.731 10.770 3.87 2.85 1.11-1.78
15.24 (600") 8.077 12.923 4.64 3.62 1.36-2.16
17.78 (700") 9.423 15.077 ― ― ―
20.32 (800") 10.770 17.231 ― ― ―
22.86 (900") 12.116 19.385 ― ― ―
25.40 (1000") 13.462 21.539 ― ― ―
*1 When the Zoom Lens (Model No.: ET-D3LEW200), the Fixed-focus Lens (Model No.: ET-D3LEU100, ET-D75LE95), or the Fisheye Lens (Model
No.: ET-D3LEF70) is used, the projection relation between the screen and the projector differs from that of other lenses. For details, refer to
“ET-D3LEU100, ET-D3LEW200” (x page 43), “ET-D75LE95” (x page 44), or “ET-D3LEF70” (x page 45).
*2 The throw ratio is based on the value during projection with the projected image size of 3.81 m (150").
r When the image aspect ratio is 16:9
(Unit: m)
Lens type Zoom Lens
Projection lens Model No.
ET-D3LEW200
*1
ET-D3LEW60/
ET-D75LE6
ET-D3LEW10 ET-D75LE10
ET-D3LES20/
ET-D75LE20
ET-D3LET30
Throw ratio
*2
0.646-0.851:1 0.924-1.10:1 1.26-1.72:1 1.30-1.67:1 1.67-2.41:1 2.40-4.66:1
Projected image size Projection distance (L)
Diagonal (SD)
Height
(SH)
Width (SW)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
Min.
(LW)
Max.
(LT)
1.78 (70") 0.872 1.550 ― ― 1.40 1.67 1.90 2.62 1.96 2.53 2.53 3.68 3.64 7.14
2.03 (80") 0.996 1.771 ― ― 1.61 1.92 2.19 3.00 2.25 2.91 2.91 4.23 4.18 8.18
2.29 (90") 1.121 1.992 ― ― 1.82 2.17 2.47 3.39 2.54 3.29 3.28 4.77 4.72 9.23
2.54 (100") 1.245 2.214 ― ― 2.03 2.42 2.76 3.78 2.83 3.67 3.65 5.31 5.25 10.28
3.05 (120") 1.494 2.657 ― ― 2.44 2.92 3.32 4.56 3.42 4.42 4.40 6.40 6.33 12.37
3.81 (150") 1.868 3.321 ― ― 3.07 3.67 4.18 5.72 4.29 5.55 5.52 8.03 7.94 15.51
5.08 (200") 2.491 4.428 2.86 3.77 4.11 4.92 5.60 7.66 5.75 7.44 7.39 10.74 10.63 20.74
6.35 (250") 3.113 5.535 3.60 4.74 5.15 6.17 7.02 9.61 7.21 9.33 9.26 13.46 13.32 25.97
7.62 (300") 3.736 6.641 4.34 5.71 6.19 7.41 8.44 11.55 8.67 11.21 11.13 16.17 16.01 31.20
8.89 (350") 4.358 7.748 5.08 6.68 7.23 8.66 9.86 13.49 10.13 13.10 12.99 18.88 18.70 36.44
10.16 (400") 4.981 8.855 5.82 7.65 8.28 9.91 11.28 15.43 11.59 14.99 14.86 21.60 21.39 41.67
12.70 (500") 6.226 11.069 7.29 9.58 10.36 12.40 14.12 19.32 14.51 18.76 18.60 27.03 26.77 52.13
15.24 (600") 7.472 13.283 8.77 11.52 12.44 14.90 16.96 23.20 17.44 22.54 22.33 32.46 32.15 62.60
17.78 (700") 8.717 15.497 ― ― 14.52 17.39 19.81 27.08 20.36 26.31 26.07 37.89 37.53 73.06
20.32 (800") 9.962 17.710 ― ― 16.61 19.89 22.65 30.97 23.28 30.09 29.81 43.31 42.92 83.53
22.86 (900") 11.207 19.924 ― ― 18.69 22.39 25.49 34.85 26.20 33.86 33.54 48.74 48.30 93.99
25.40 (1000") 12.453 22.138 ― ― 20.77 24.88 28.33 38.73 29.12 37.63 37.28 54.17 53.68 104.45
