14-20
Address
FP0 T32
FP0 C10,
C14, C16,
C32, SL1
Name Descriptions
-
DT9021
(Availabl
e type:
SL1)
No. of units connected
to S-LINK/error
address
(When normal)
Note
- When the SET switch is pressed, the number
of input/output units connected to the S-LINK
system is set.
(If the same address has been specified for
multiple units, the units are counted as a single
unit. This is invalid, however, if an ERR4 error is
in progress.)
(If ERR4 occurs)
DT90022 DT9022
Scan time (current
value)
(*Note)
The current scan time is stored here. Scan time
is calculated using the formula:
Scan time (ms) = stored data (decimal) x 0.1
K50 indicates 5 ms.
Scan time display is only possible in RUN mode, and shows the operation cycle time. The maximum and
minimum values are cleared when each the mode is switched between RUN mode and PROG. mode.
