Parker 690+ series - Page 151

Parameter Specification 2-7
690+ Series Frequency Inverter
TAG MMI Name Block
736 INVERT DIGITAL OUTPUT 3
1534 INVERT ENCODER SPEED 1
1542 INVERT ENCODER SPEED 2
1154 INVERT ENC TRIP I/O TRIPS
1487 INVERT OUTPUT PHASE CONTROL
1482 INVERT SPEED OP PHASE CONTROL
760 INVERT THERMIST I/O TRIPS
1152 IT LIMITING INVERSE TIME
890 JERK 1 S-RAMP
891 JERK 2 S-RAMP
892 JERK 3 S-RAMP
893 JERK 4 S-RAMP
280 JOG SEQUENCING LOGIC
302 JOGGING SEQUENCING LOGIC
1608 kW min ENERGY METER
120 LEAKAGE INDUC MOTOR DATA
1519 LIMIT PHASE PID
1253 LIMIT PID (TYPE 2)
1683 LIMIT POSITION
1523 LIMITING PHASE PID
1257 LIMITING PID (TYPE 2)
811 LINE SPD DEMAND COMPENSATION
830 LINE SPEED DIAMETER CALC
778 LINE SPEED SPEED CALC
820 LINE SPEED RATE COMPENSATION
1533 LINES ENCODER SPEED 1
1541 LINES ENCODER SPEED 2
250 LOCAL REVERSE REFERENCE
247 LOCAL SETPOINT REFERENCE
53 LOW LIMIT DISPLAY SCALE 1
675 LOW LIMIT DISPLAY SCALE 2
858 LOW LIMIT DISPLAY SCALE 3
866 LOW LIMIT DISPLAY SCALE 4
328 LOWER INPUT RAISE/LOWER
65 MAG CURRENT MOTOR DATA
1566 MARK OFFSET PHASE REGISTER
1837 MASTER INVERT PHASE CONFIGURE
1598 MASTER LENGTH PHASE AUTO GEAR
1833 MASTER MARK POS PHASE AUTO GEAR
1561 MASTER MARK TYPE PHASE CONFIGURE
1590 MASTER MARKS PHASE AUTO GEAR
1491 MASTER POS (INT) PHASE CONTROL
1529 MASTER POSITION PHASE CONFIGURE
1492 MASTER POSITION PHASE CONTROL
1527 MASTER SCALE A PHASE CONFIGURE
1528 MASTER SCALE B PHASE CONFIGURE
1535 MAX SPEED ENCODER SPEED 1
1543 MAX SPEED ENCODER SPEED 2
1560 MAX SPEED PHASE CONFIGURE
1032 MAX SPEED SETPOINT SCALE
252 MAX SPEED CLAMP REFERENCE
330 MAX VALUE RAISE/LOWER
575 MIN SEARCH SPEED FLYCATCHING
253 MIN SPEED CLAMP REFERENCE
329 MIN VALUE RAISE/LOWER
337 MINIMUM MINIMUM SPEED
806 MINIMUM DIAMETER COMPENSATION
831 MINIMUM DIAMETER DIAMETER CALC
781 MINIMUM DIAMETER SPEED CALC
832 MINIMUM SPEED DIAMETER CALC
1592 MISSED M MARKS PHASE AUTO GEAR
1591 MISSED S MARKS PHASE AUTO GEAR
836 MOD LINE SPEED DIAMETER CALC
816 MOD WINDER SPEED COMPENSATION
837 MOD WINDER SPEED DIAMETER CALC
779 MOD WINDER SPEED SPEED CALC
TAG MMI Name Block
689 MODE AUTOTUNE
338 MODE MINIMUM SPEED
117 MODE SYSTEM PORT (P3)
124 MOTOR CONNECTION MOTOR DATA
64 MOTOR CURRENT MOTOR DATA
66 MOTOR CURRENT % FEEDBACKS
67 MOTOR CURRENT A FEEDBACKS
84 MOTOR POLES MOTOR DATA
1160 MOTOR VOLTAGE MOTOR DATA
85 MOTORING LIMIT SLIP COMP
1842 MSTR POS+OFFSET PHASE CONTROL
121 MUTUAL INDUC MOTOR DATA
324 NAME OPERATOR MENU 1
1073 NAME OPERATOR MENU 10
1077 NAME OPERATOR MENU 11
1081 NAME OPERATOR MENU 12
1085 NAME OPERATOR MENU 13
1089 NAME OPERATOR MENU 14
1093 NAME OPERATOR MENU 15
1097 NAME OPERATOR MENU 16
1741 NAME OPERATOR MENU 17
1746 NAME OPERATOR MENU 18
1751 NAME OPERATOR MENU 19
378 NAME OPERATOR MENU 2
1756 NAME OPERATOR MENU 20
1761 NAME OPERATOR MENU 21
1766 NAME OPERATOR MENU 22
1771 NAME OPERATOR MENU 23
1776 NAME OPERATOR MENU 24
1781 NAME OPERATOR MENU 25
1786 NAME OPERATOR MENU 26
1791 NAME OPERATOR MENU 27
1796 NAME OPERATOR MENU 28
1801 NAME OPERATOR MENU 29
1045 NAME OPERATOR MENU 3
1806 NAME OPERATOR MENU 30
1811 NAME OPERATOR MENU 31
1816 NAME OPERATOR MENU 32
1049 NAME OPERATOR MENU 4
1053 NAME OPERATOR MENU 5
1057 NAME OPERATOR MENU 6
1061 NAME OPERATOR MENU 7
1065 NAME OPERATOR MENU 8
1069 NAME OPERATOR MENU 9
83 NAMEPLATE RPM MOTOR DATA
791 NEG TORQUE LIMIT TORQUE CALC
1259 NEGATE 5703 INPUT
1038 NO SETPOINT PWRD ACCESS CONTROL
1582 NOM MASTER LEN PHASE AUTO GEAR
1583 NOM SLAVE LENGTH PHASE AUTO GEAR
278 NOT COAST STOP SEQUENCING LOGIC
277 NOT FAST STOP SEQUENCING LOGIC
293 NOT STOP SEQUENCING LOGIC
586 OFF FREQUENCY BRAKE CONTROL
588 OFF HOLD TIME BRAKE CONTROL
15 OFFSET ANALOG INPUT 1
24 OFFSET ANALOG INPUT 2
714 OFFSET ANALOG INPUT 3
721 OFFSET ANALOG INPUT 4
47 OFFSET ANALOG OUTPUT 1
733 OFFSET ANALOG OUTPUT 2
802 OFFSET ANALOG OUTPUT 3
1510 OFFSET PHASE OFFSET
1511 OFFSET FINE PHASE OFFSET
585 ON FREQUENCY BRAKE CONTROL
587 ON HOLD TIME BRAKE CONTROL
