2-8 Parameter Specification
690+ Series Frequency Inverter
TAG MMI Name Block
584 ON LOAD BRAKE CONTROL
115 OP DATABASE OP STATION 1
1497 OP DATABASE OP STATION 2
230 OP VERSION OP STATION 1
1110 OP VERSION OP STATION 2
1104 OUTPUT FILTER 1
1108 OUTPUT FILTER 2
1472 OUTPUT HOME
887 OUTPUT LINEAR RAMP
183 OUTPUT LOGIC FUNC 1
228 OUTPUT LOGIC FUNC 10
1349 OUTPUT LOGIC FUNC 11
1354 OUTPUT LOGIC FUNC 12
1359 OUTPUT LOGIC FUNC 13
1364 OUTPUT LOGIC FUNC 14
1369 OUTPUT LOGIC FUNC 15
1374 OUTPUT LOGIC FUNC 16
1379 OUTPUT LOGIC FUNC 17
1384 OUTPUT LOGIC FUNC 18
1389 OUTPUT LOGIC FUNC 19
188 OUTPUT LOGIC FUNC 2
1394 OUTPUT LOGIC FUNC 20
193 OUTPUT LOGIC FUNC 3
198 OUTPUT LOGIC FUNC 4
203 OUTPUT LOGIC FUNC 5
208 OUTPUT LOGIC FUNC 6
213 OUTPUT LOGIC FUNC 7
218 OUTPUT LOGIC FUNC 8
223 OUTPUT LOGIC FUNC 9
335 OUTPUT MINIMUM SPEED
598 OUTPUT MULTIPLEXER 1
873 OUTPUT MULTIPLEXER 2
1488 OUTPUT PHASE CONTROL
1522 OUTPUT PHASE PID
1256 OUTPUT PID (TYPE 2)
325 OUTPUT RAISE/LOWER
59 OUTPUT SETPOINT SCALE
346 OUTPUT SKIP FREQUENCIES
767 OUTPUT S-RAMP
133 OUTPUT VALUE FUNC 1
178 OUTPUT VALUE FUNC 10
1299 OUTPUT VALUE FUNC 11
1304 OUTPUT VALUE FUNC 12
1309 OUTPUT VALUE FUNC 13
1314 OUTPUT VALUE FUNC 14
1319 OUTPUT VALUE FUNC 15
1324 OUTPUT VALUE FUNC 16
1329 OUTPUT VALUE FUNC 17
1334 OUTPUT VALUE FUNC 18
1339 OUTPUT VALUE FUNC 19
138 OUTPUT VALUE FUNC 2
1344 OUTPUT VALUE FUNC 20
143 OUTPUT VALUE FUNC 3
148 OUTPUT VALUE FUNC 4
153 OUTPUT VALUE FUNC 5
158 OUTPUT VALUE FUNC 6
163 OUTPUT VALUE FUNC 7
168 OUTPUT VALUE FUNC 8
173 OUTPUT VALUE FUNC 9
748 OUTPUT (INT) POSITION
657 OUTPUT 0 DEMULTIPLEXER 1
875 OUTPUT 0 DEMULTIPLEXER 2
658 OUTPUT 1 DEMULTIPLEXER 1
1000 OUTPUT 1 DEMULTIPLEXER 2
356 OUTPUT 1 PRESET 1
389 OUTPUT 1 PRESET 2
TAG MMI Name Block
399 OUTPUT 1 PRESET 3
519 OUTPUT 1 PRESET 4
530 OUTPUT 1 PRESET 5
541 OUTPUT 1 PRESET 6
552 OUTPUT 1 PRESET 7
563 OUTPUT 1 PRESET 8
758 OUTPUT 1 TEC OPTION
667 OUTPUT 10 DEMULTIPLEXER 1
1009 OUTPUT 10 DEMULTIPLEXER 2
668 OUTPUT 11 DEMULTIPLEXER 1
1010 OUTPUT 11 DEMULTIPLEXER 2
669 OUTPUT 12 DEMULTIPLEXER 1
1011 OUTPUT 12 DEMULTIPLEXER 2
670 OUTPUT 13 DEMULTIPLEXER 1
1012 OUTPUT 13 DEMULTIPLEXER 2
671 OUTPUT 14 DEMULTIPLEXER 1
1013 OUTPUT 14 DEMULTIPLEXER 2
672 OUTPUT 15 DEMULTIPLEXER 1
1014 OUTPUT 15 DEMULTIPLEXER 2
659 OUTPUT 2 DEMULTIPLEXER 1
1001 OUTPUT 2 DEMULTIPLEXER 2
372 OUTPUT 2 PRESET 1
373 OUTPUT 2 PRESET 2
374 OUTPUT 2 PRESET 3
520 OUTPUT 2 PRESET 4
531 OUTPUT 2 PRESET 5
542 OUTPUT 2 PRESET 6
553 OUTPUT 2 PRESET 7
564 OUTPUT 2 PRESET 8
759 OUTPUT 2 TEC OPTION
660 OUTPUT 3 DEMULTIPLEXER 1
1002 OUTPUT 3 DEMULTIPLEXER 2
661 OUTPUT 4 DEMULTIPLEXER 1
1003 OUTPUT 4 DEMULTIPLEXER 2
662 OUTPUT 5 DEMULTIPLEXER 1
1004 OUTPUT 5 DEMULTIPLEXER 2
663 OUTPUT 6 DEMULTIPLEXER 1
1005 OUTPUT 6 DEMULTIPLEXER 2
664 OUTPUT 7 DEMULTIPLEXER 1
1006 OUTPUT 7 DEMULTIPLEXER 2
665 OUTPUT 8 DEMULTIPLEXER 1
1007 OUTPUT 8 DEMULTIPLEXER 2
666 OUTPUT 9 DEMULTIPLEXER 1
1008 OUTPUT 9 DEMULTIPLEXER 2
286 OUTPUT CONTACTOR SEQUENCING LOGIC
363 OUTPUT Hz SKIP FREQUENCIES
318 OUTPUT NEG LIMIT PID
317 OUTPUT POS LIMIT PID
1486 OUTPUT SCALE PHASE CONTROL
319 OUTPUT SCALING PID
776 OVER SPD ENABLE SPEED CALC
782 OVER SPEED SPEED CALC
1164 OVERLOAD MOTOR DATA
775 OVER-WIND SPEED CALC
786 OVER-WIND TORQUE CALC
1516 P GAIN PHASE PID
1250 P GAIN PID (TYPE 2)
74 PARAMETER OPERATOR MENU 1
633 PARAMETER OPERATOR MENU 10
634 PARAMETER OPERATOR MENU 11
635 PARAMETER OPERATOR MENU 12
636 PARAMETER OPERATOR MENU 13
637 PARAMETER OPERATOR MENU 14
638 PARAMETER OPERATOR MENU 15
639 PARAMETER OPERATOR MENU 16
1740 PARAMETER OPERATOR MENU 17
